Summary of Contents for Akces-Med KIDOO HOME
- Page 1 S P E C I A L N E E D S S T R O L L E R K I D O O H O M E ™ USER MANUAL...
- Page 2 Akces-MED Ltd. employee or at specialized medical store! Akces-MED Ltd. reserve the right to introduce technical and trading changes in the content of the instruction without warning. Product marked with the CE sign is Class I medical device, of...
-
Page 3: Table Of Contents
KIDOO HOME CONTENTS 1. The purpose of user manual......................5 2. Indications and contrindications for use..................5 3. General characteristics of stroller ....................6 3.1 Standard equipment......................6 3.2 Additional equipment......................7 4. Size table............................8 5. Description how to use stroller....................9 6. Additional equipment.........................15 6.1 KDH_155 Laterall supports....................15 KDH_134/KDH_137 Narrowing pads 6 cm/10 cm.............16... - Page 4 KIDOO HOME CONTENTS KIDOO HOME™ is a special needs stroller which is perfect both for therapy and recreation, as well as other every day activities such as learning or having meals. The stroller can be used at home, school, in the kindergarten or in a group of peers.
-
Page 5: The Purpose Of User Manual
KIDOO HOME THE PURPOSE OF USER MANUAL The instruction manual contains basic information necessary to properly prepare the stroller before use, use the stroller, maintain and clean the stroller This user manual should be kept in an easily accessible place. The manual is intended for people who look after disabled users, as well as for doctors and physiotherapists handling the stroller. -
Page 6: General Characteristics Of Stroller
KIDOO HOME GENERAL CHARACTERISTICS OF STROLLER 3.1. Standard equipment: 1. Adjustable backrest tilt angle, 2. Tilt-In-space adjustment, 3. Adjustable depth of the seat, 4. Adjustable armrests, 5. 4 points safety vest, 6. Push handle, 7. HexagonPro™ Headrest, 8. Mobile base with footrest and 2 points feet stabilizing belts, 9.Medical upholstery MEDICUS™... -
Page 7: Additional Equipment
KIDOO HOME 3.2. Additional equipment KDH_014 KDH_101 KDH_107 Skis/Rocking stroller Thigh abduction belts Pelvic belt KDH_124 KDH_154 KDH_114 KDH_125 6 points safety vest Loins support KDH_154 KDH_154 KDH_137 KDH_134 Narrowing pads 6 cm Narrowing pads 10 cm Knee abductor KDH_155... - Page 8 KIDOO HOME KDH_436 KDH_443 KDH_616 Footrest with 2 points feet KIDOO™ table JOY™ table stabilizing belts KDH_617 KDH_619 KDH_620 KDH_616 Baza jezdna KDH_616 Baza jezdna KDH_616 Baza jezdna Mobile base Footrest Mobile base with footrest www.akces-med.com +48 17 864 04 70...
-
Page 9: Size Table
KIDOO HOME SIZE TABLE Symbol Measureme Size 2 Size 1 Size 3 Size 4 Size 5 Unit [cm] 90-115 100-130 110-150 Indicative user height* 90-100 120-160 [cm] 26,5 Seat width Seat depth [cm] 18-23,5 22,5-30 24,5-34,5 31-41 36-47 Backrest height... - Page 10 KIDOO HOME DESRIPTION HOW TO USE STROLLER 5.1. Seat Loosen the A knobs to adjust the seat depth. Knobs can be found under the seat. Adjust needed depth and fix the knobs tightly. fig.2 fig.1 5.2. Backrest The backrest tilt angle depends on the dysfunction type and adaptation level of...
- Page 11 KIDOO HOME CAUTION! When the backrest angle is set on in 3 or 4 position it is necessary to use the stroller with the skis. Skis also helps to stabilise and prevent tip over and stroller 5.3. Armrest To adjust height and angle the armrest please loosen the C knob, adjust the needed position and fix the knob tightly.
- Page 12 KIDOO HOME fig.8 fig.7 5.5. Tilt-In-Space Tilt is a space function is available thanks to the legs height adjustment. While the seat tilt is more than 7,5 ° we strongly recommend use the stroller with skis. CAUTION! When stroller adjusted in tilt in space position (and when the backrest angle is set on in 3 or 4 position) it is necessary to use the stroller with the skis.
- Page 13 KIDOO HOME 5.6. HexagonPro© Headrest 5.6.1. Assembly of headrest To assemble the headrest you should place it next to the special holes in backrest and screw with two included bolts with Allen key. fig.9 fig.10 5.6.2. Adjustment of the headrest The headrest may be adjusted with Allen key.
- Page 14 KIDOO HOME 5.7. Mobile base with footrest Bases and anti-tip wheels are assembled to the frame of the stroller on each side. fig.13 Mobile base with footrest – place of attachment Metric screw Steel washer Elements are assembled to the...
-
Page 15: Additional Equipment
KIDOO HOME ADDITIONAL EQUIPMENT KDH_155 6.1. Laterall supports To assemble the laterall supports you should: STEP 1. Remove the backrest cushion and place the laterall supports in the required height (fig. 16, 17). fig.16 fig.17 STEP 2. To assemble the laterall supports there is necessary to put the screw with washer in the front (fig. -
Page 16: Kdh_134/Kdh_137 Narrowing Pads 6 Cm/10 Cm
KIDOO HOME KDH_134 6.2. Narrowing pads 6 cm KDH_137 Narrowing pads 10 cm Narrowing pads are assembled to forearm rests with special Velcro. fig.20 fig.21 KDH_154 6.3. Knee abductor KDH_128 Abduction block To assemble the knee abductor (fig. ) or the abduction block (fig. - Page 17 KIDOO HOME KDH_617 6.4. Mobile base KDH_014 Skis/Rocking stroller Bases and anti-tip wheels are assembled to the frame of the stroller on each side. Skis – place of attachment fig.27 fig.26 Mobile base – place of attachment Metric screw Steel washer...
-
Page 18: Kdh_403 Tray
KIDOO HOME fig.30 fig.31 Additionally, KIDOO HOME™ can be converted into comfortable rocking stroller. To do that, there is necessary assemble skis in the other way . 6.5. KDH_403 Tray Please follow below steps before assembling the tray: - set up both armrests at the same high... -
Page 19: The Use Of Stroller
Remember to use the product only with someone who is trained and knowledgeable. Do not forget to prepare both product as well as patient before using KIDOO HOME™ stroller 7.1. Preparation of the patient Before using the product, it is essential to make sure that: patient's outfit is light and comfortable sporty clothes are advisable;... -
Page 20: Preparation Of The Stroller
KIDOO HOME 7.2. Preparation of the stroller 1. Before use it is necessary to: Unfold the device; § Place the device on even ground; § Make sure that all parts are serviceable, correctly mounted and stable; § Block brakes; §... -
Page 21: How To Use Vest
KIDOO HOME 7.3. How to use vest The vest provides posture support for wheelchair users as well as users sitting in positioning chairs or other rehabilitation seats. When properly used, the vest allows the user to adopt the correct sitting position for a longer period of time. The design and shape of the vest make it possible for the user to be free to move their upper limbs within the constraints of the user. - Page 22 KIDOO HOME Instructions for the proper use of the vest: 1) Make sure that the user is sitting in the best possible position: in the middle of the seat, § deeply in the seat in such a way that the user's lumbar spine rests against the §...
- Page 23 KIDOO HOME 4) It should be remembered that any change of the inclination angle of the backrest, seat, foot support or tilt-in-space function might affect the effectiveness of the belts and supports! 5) Special attention should be paid to the use of stabilization elements or side supports. If the user has poor trunk control, the side supports will limit the lateral movements, which could lead to the compression of the vest straps on the neck of the user.
-
Page 24: Safety Rules
KIDOO HOME SAFETY RULES CAUTION! KIDOO HOME™ stroller has to be used in compliance with guidelines in this user manual. It is highly important to consult either doctor or physiotherapist in order to make right decision concerning the choice of stroller and its size. It is also essential to familiarize with the guidelines described in user manual before using the device. - Page 25 KIDOO HOME 2. It is forbidden to use stroller for different purposes that it is intended to. 3. It is forbidden to use stroller when it is damaged or any part is missing. 4. It is forbidden to leave the patient unattended.
-
Page 26: Terms Of Warranty
Next, manufacturer determines again how long the product can be used and, moreover, the date of the next service will be determined. If product is damaged, please contact our dealer or Akces-MED Ltd. customer service § (ph. +48 17 864 04 77, e-mail: export@akces-med.com). -
Page 27: Maintenance And Cleaning
KIDOO HOME MAINTENANCE AND CLEANING The stroller KIDOO HOME™ which is a medical device, should always be kept clean and should be used in accordance with the manufacturer's instructions. The stroller should be kept in a clean, dry and ventilated room. Maintenance and cleaning must be done at least once a month. - Page 28 KIDOO HOME Before using it is necessary to: clean wheels; § check if base as well as wheels are correctly mounted; check if brake stops turning § wheel; check if wheelchair construction is free of breaks or any kinds of deformities;...
- Page 29 KIDOO HOME TECHNICAL INSPECTION Technical inspections should be performed regularly. Before servicing, the product should be thoroughly cleaned to reveal any hidden damage. Frequency What should be checked? What should be done? Remarks Before each use. General condition of Check:...
- Page 30 KIDOO HOME Frequency What should be checked? What should be done? Remarks Once a month. Wheel axles, quick connec- Check: Clean the wheels when dirty. tors (if applicable). if the wheels are rolling and if they are not In case of any damage or defects, ź...
-
Page 31: Labelling
KIDOO HOME LABELLING 12.1. Symbols Declaration that the product meets Dry vertically the essential requirements Catalog number Do not chlorinate Serial number Do not iron Please read the manual instructions before Do not dry in a drum dryer You need to take special precautions... - Page 32 MANUFACTURER Akces-MED Ltd. Jasionka 955B 36-002 Jasionka ph. +48 17 864 04 77 e-mail: export@akces-med.com BDO: 000031619 Authorised Dealer Date of issue: 23.06.2016 The last update: 20.05.2021 © Sławomir Wroński 2021...
