Summary of Contents for Akces-Med KIDOO HOME
- Page 1 KIDOO HOME ™ SPECIAL NEEDS STROLLER USER MANUAL...
- Page 2 CAUTION! Manufacturer takes responsibility for proper usage of the device only when the product was purchased from qualified Akces-Med employee or at specialized medical store! CAUTION! AKCES-MED Ltd. reserve the right to introduce technical and trading changes in the content of the instruction without warning.
-
Page 3: Table Of Contents
KIDOO HOME CONTENTS The purpose of user manual ....................5 2. Indications for use.........................5 3. General characteristics of stroller ....................6 3.1 Standard equipment......................6 3.2 Additional equipment......................7 4. Size table............................8 5. Description how to use stroller......................9 6. Additional equipment.........................15 6.1 KDH_155 Laterall supports.....................15 KDH_134/KDH_137 Narrowing pads 6 cm/10 cm.. - Page 4 KIDOO HOME CONTENTS KIDOO HOME™ is a special needs stroller which is perfect both for therapy and recreation, as well as other every day activities such as learning or having meals. The stroller can be used at home, school, in the kindergarten or in a group of peers.
-
Page 5: The Purpose Of User Manual
The present user manual contains basic information which is essential for proper usage, preparation, maintenance, cleaning and guarantee conditions regarding KIDOO HOME™ stroller. User manual should be kept in easily accessible place. It is designed for people who look after disabled children, and for both doctors as well as physiotherapists who operate the device. -
Page 6: General Characteristics Of Stroller
KIDOO HOME GENERAL CHARACTERISTICS OF STROLLER 3.1. Standard equipment: 1. Adjustable depth of the seat, Tilt-In-space adjustment 2. Adjustable backrest tilt angle 3. Adjustable armrests 4. 4 points safety belts with a Velcro fastening 5. Push handle 6. HexagonPro Headrest™... -
Page 7: Additional Equipment
KIDOO HOME 3.2. Additional equipment KDH_014 KDH_101 KDH_107 Skis/Rocking stroller Thigh abduction belts Pelvic belt KDH_114 KDH_128 KDH_125 6 points safety vest H Harness Abduction block KDH_154 KDH_154 KDH_137 KDH_134 Narrowing pads 6 cm Narrowing pads 10 cm Knee abductor... - Page 8 KIDOO HOME KDH_436 KDH_443 KDH_616 Footrest with 2 points feet KIDOO™ table JOY™ table stabilizing belts KDH_617 KDH_619 KDH_620 KDH_616 Baza jezdna KDH_616 Baza jezdna KDH_616 Baza jezdna Mobile base Footrest Mobile base with footrest www.akces-med.com +48 17 864 04 70...
-
Page 9: Size Table
KIDOO HOME SIZE TABLE Symbol Measureme Size 2 Size 1 Size 3 Size 4 Size 5** Unit [cm] 90-115 100-130 110-150 Indicative user height* 90-100 120-160 [cm] 26,5 Seat width Seat depth [cm] 18-23,5 22,5-30 24,5-34,5 31-41 36-47 Backrest height... - Page 10 KIDOO HOME DESRIPTION HOW TO USE STROLLER 5.1. Seat Loosen the A knobs to adjust the seat depth. Knobs can be found under the seat. Adjust needed depth and fix the knobs tightly. fig.2 fig.1 5.2. Backrest The backrest tilt angle depends on the dysfunction type and adaptation level of...
- Page 11 KIDOO HOME CAUTION! When the backrest angle is set on in 3 or 4 position it is necessary to use the stroller with the skis. Skis also helps to stabilise and prevent tip over and stroller 5.3. Armrest To adjust height and angle the armrest please loosen the C knob, adjust the needed position and fix the knob tightly.
- Page 12 KIDOO HOME fig.8 fig.7 5.5. Tilt-In-Space Tilt is a space function is available thanks to the legs height adjustment. While the seat tilt is more than 7,5 ° we strongly recommend use the stroller with skis. CAUTION! When stroller adjusted in tilt in space position (and when the backrest angle is set on in 3 or 4 position) it is necessary to use the stroller with the skis.
- Page 13 KIDOO HOME 5.6. HexagonPro© Headrest 5.6.1. Assembly of headrest To assemble the headrest you should place it next to the special holes in backrest and screw with two included bolts with Allen key. fig.9 fig.10 5.6.2. Adjustment of the headrest The headrest may be adjusted with Allen key.
- Page 14 KIDOO HOME 5.7. Mobile base with footrest Bases and anti-tip wheels are assembled to the frame of the stroller on each side. fig.13 Mobile base with footrest – place of attachment Metric screw Steel washer Elements are assembled to the...
-
Page 15: Additional Equipment
KIDOO HOME ADDITIONAL EQUIPMENT KDH_155 6.1. Laterall supports To assemble the laterall supports you should: STEP 1. Remove the backrest cushion and place the laterall supports in the required height (fig. 16, 17). fig.16 fig.17 STEP 2. To assemble the laterall supports there is necessary to put the screw with washer in the front (fig. -
Page 16: Kdh_134/Kdh_137 Narrowing Pads 6 Cm/10 Cm
KIDOO HOME KDH_134 6.2. Narrowing pads 6 cm KDH_137 Narrowing pads 10 cm Narrowing pads are assembled to forearm rests with special Velcro. fig.20 fig.21 KDH_154 6.3. Knee abductor KDH_128 Abduction block To assemble the knee abductor (fig. ) or the abduction block (fig. -
Page 17: Kdh_617/Kdh_014 Mobile Base/Sisk
KIDOO HOME KDH_617 6.4. Mobile base KDH_014 Skis/Rocking stroller Bases and anti-tip wheels are assembled to the frame of the stroller on each side. Skis – place of attachment fig.27 fig.26 Mobile base – place of attachment Metric screw Steel washer... -
Page 18: Kdh_403 Tray
KIDOO HOME fig.30 fig.31 Additionally, KIDOO HOME™ can be converted into comfortable rocking stroller. To do that, there is necessary assemble skis in the other way . 6.5. KDH_403 Tray Please follow below steps before assembling the tray: set up both armrests at the same high... -
Page 19: The Use Of Stroller
Remember to use the product only with someone who is trained and knowledgeable. Do not forget to prepare both product as well as patient before using KIDOO HOME™ stroller 7.1. Preparation of the patient Before using the product, it is essential to make sure that: patient's outfit is light and comfortable sporty clothes are advisable;... - Page 20 KIDOO HOME 7.2. Preparation of the stroller 1. Before use it is necessary to: Unfold the device; § Place the device on even ground; § Make sure that all parts are serviceable, correctly mounted and stable; § Block brakes; §...
- Page 21 KIDOO HOME CAUTION! Incorrect adjustment of the device can lead to side effects such as: fainting, body deformities, overloading joints. It is highly advisable to adjust the device before every use of a standing frame. This adjustment has to be done only by a trained person or therapist.
-
Page 22: Safety Rules
KIDOO HOME SAFETY RULES CAUTION! KIDOO HOME™ stroller has to be used in compliance with guidelines in this user manual. It is highly important to consult either doctor or physiotherapist in order to make right decision concerning the choice of stroller and its size. It is also essential to familiarize with the guidelines described in user manual before using the device. - Page 23 KIDOO HOME 2. It is forbidden to use stroller for different purposes that it is intended to. 3. It is forbidden to use stroller when it is damaged or any part is missing. 4. It is forbidden to leave the patient unattended.
- Page 24 This device can be only used inside the buildings. 1) AKCES-MED Sp. z. o. o sells products free from manufacturing defects or faults. 2) Manufacturer gives the purchaser 24-month guarantee from the date of purchase. All defects revealed during warranty period will be repaired free of charge.
-
Page 25: Maintenance And Cleaning
4. It is forbidden to clean upholstery with strong chemical agents such as solvent or caustic chemicals. CAUTION! Akces-MED Sp z o. o takes no responsibility for damages caused by use of wrong clearing agent. 5. It is forbidden to soak upholstery during cleaning. Remember that upholstery has to be always dry before using. - Page 26 KIDOO HOME CAUTION! Remember that upholstery has to be always dry before using! Before using it is necessary to: clean wheels; § check if base as well as wheels are correctly mounted; check if brake stops § turning wheel make sure that all wooden parts e.g. tray don't have splinters §...
- Page 28 ORTHOPAEDIC DEVICES MANUFACTURER Akces-MED Sp. z o.o. Jasionka 955B 36-002 Jasionka tel. (17) 864 04 77 www.akces-med.com e-mail: export@akces-med.com Authorised Dealer Date of issue: 23.06.2016 The last update: 22.11.2018...
