- Page 1 ULISESevo ™ SPECIAL NEEDS STROLLER ASSEBBLY MANUAL...
- Page 2 CAUTION! Manufacturer takes responsibility for proper usage of the device only when the product was purchased from qualified Akces-Med employee or at specialized medical store! CAUTION! AKCES-MED Ltd. reserve the right to introduce technical and trading changes in the content of the instruction without warning.
-
Page 3: Table Of Contents
ULISESevo CONTENTS 1.Components...........................4 2.Detailed assembly instruction....................6 2.1 Stroller frame.......................6 2.2 Footrest........................7 2.3 Front wheels.......................7 2.4 Rear wheels......................10 2.5 Seat upholstery......................11 2.6 Backrest upholstery....................14 2.7 Headrest........................16 2.8 5-points belts......................18 www.akces-med.com +48 17 864 04 70 export@akces-med.com... -
Page 4: Components
ULISESevo COMPONENTS (long Allen screw x 2 pcs.) rear inflatable wheel x 2 pcs.) (spacer bushing x 4 pcs.) (front PU wheel x 2 pcs.) (front wheel fork x 2 pcs.) (wheel bolt cap x 2 pcs.) (short Allen screw x 2 pcs.) (flat washer x 2 pcs.) - Page 5 ULISESevo (upholstery – seat x 1 pc.) (upholstery – backrest x 1 pc.) (upholstery – bottom seat x 1 pc.) (small Allen screw x 2 pcs.) (headrest x 1 pc.) (5-point belt strap x 2 pcs.) (5-point belt cover with fastening x 1 pc.) (long belt with fastening x 1 pc.)
-
Page 6: Detailed Assembly Instruction
ULISESevo DETAILED ASSEMBLY INSTRUCTION 2.1. STROLLER FRAME In order to unfold the stroller frame (14), you should set the backrest tubes vertically (fig.1). Afterwards, pull the stroller push handle backwards until the folding mechanism snaps. (pic.2, 3). pic.1 pic.2 pic.3 2.2. -
Page 7: Front Wheels
ULISESevo pic.6 pic.7 2.3. FRONT WHEELS The next step is assembly of the front wheels (2). In order to do that, you should, in the correct order, put the flat washer (4) and large flat washer (5) on the wheel fork (9), and then stick the short screw (10) from the bottom (pic 8.) Afterwards,... - Page 8 ULISESevo Insert the long Allen screw (7) into the round hole as shown in the picture (pic.11). Then, put the spacer bushing (8) and PU wheel (2) on it (pic 12). The spacer bushing should be placed between the inner side of the wheel fork and wheel.
- Page 9 ULISESevo The screw should be tightened by use of Allen wrench (pic. 14) so that the screw head is not fully tightened (pic.15). pic.14 pic.15 Insert the self-locking nut (6) into the hexagonal hole as shown in the picture (pic. 16, 17), and then fully tighten the screw.
-
Page 10: Rear Wheels
ULISESevo 2.4. REAR WHEELS The next step is assembly of the rear wheels (1). Insert the hexagon head bolt (12) into the hole from the outer side (pic. 18,19). Afterwards, put the bolt pad (11) from the other side (pic. 20, 21). -
Page 11: Seat Upholstery
ULISESevo pic.24 pic.25 pic.26 pic.27 Repeat the above with the second large wheel. 2.5.SEAT UPHOLSTERY In order to attach the upholstery, you should first assemble the bottom of the seat (17) (pic. 28). To do that, put the upholstery on the seat frame. Keep in mind that strap buckles should be facing downwards. - Page 12 ULISESevo Fasten the upholstery to the frame by use of Velcro straps. The last strap (strap No. 3) should be interlaced through the opening indicated in the picture (pic.29,30), and then fasten all 3 straps with Velcro from the seat underside (pic 31,32).
- Page 13 ULISESevo Fasten the seat upholstery to the stroller frame by use of Velcro straps (pic. 35). Make sure that straps cover the seat frame. pic.35 The straps should be fastened so as to overlap with the opening in the frame.
-
Page 14: Backrest Upholstery
ULISESevo In the final step, fasten the Velcro straps under the seat close to the footrest (pic.40). pic.40 BACKREST UPHOLSTERY 2.6. To prepare the backrest upholstery (16) for attachment, you should first unfasten the zipper in the upper part of the upholstery (pic. 41,42). - Page 15 ULISESevo The upholstery should be fastened behind the backrest by use of Velcro strap (pic 45, 47). Make sure that straps cover the backrest frame. pic.45 pic.47 pic.46 In order to make fastening of the last bottom belt easier, it is recommended to bend the backrest forward.
-
Page 16: Headrest
ULISESevo pic.50 pic.51 In the final step, fasten the flap located in the lower part of the backrest using Velcro (pic. 52, 53). pic.52 pic.53 2.7. HEADREST In order to assemble the headrest (19), you should insert the strings, contained in the headrest, into the upholstery holes at the desired height (pic 54-56). - Page 17 ULISESevo pic.56 pic.57 Then, insert the straps with buckle, located next to the headrest, into the upholstery holes (pic. 58) and fasten them behind the backrest (pic. 59). pic.58 pic.59 Afterwards, fasten the zipper in the upper part of the backrest (pic. 60, 61).
-
Page 18: 5-Points Belts
ULISESevo 2.8. 5-POINT BELTS In order to attach the 5-point belts, you should first attach the long belt with fastening (22) (pic. 62, 63). The scheme below shows the proper attachment of the belt. By pulling the belt, make sure that... - Page 19 ULISESevo Attach the 5-point belt cover (21) onto the straps (pic.67). Then, insert the straps into the seat belt fastening (pic. 68, 69). pic.67 pic.68 pic.69 The ends of the straps have to be interlaced through the triangular elements located at the sides of the stroller (pic.
- Page 20 ORTHOPAEDIC DEVICES MANUFACTURER Akces-MED Sp. z o.o. Jasionka 955B 36-002 Jasionka tel. (17) 864 04 77 www.akces-med.com e-mail: export@akces-med.com Authorised Dealer Date of issue: 22.09.2016 The last update: 22.09.2016...
