Vision Edgeless
Made in Sweden
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Vision Edgeless and is the answer not in the manual?

Questions and answers

Related Manuals for Euroscreen Vision Edgeless

Summary of Contents for Euroscreen Vision Edgeless

  • Page 1 02 jan. 2020, 08:01 Vision Edgeless Made in Sweden...
  • Page 2 Please read through the manual completely before installation and usage. Tack för att ni valt en Euroscreen som en del i er AV-installation. Vi ® hoppas den kan ge er många timmar av underhållning och/eller utbildning, beroende på...
  • Page 3 Overview / Översikt Case / Kassett fig 1 Edgeless bracket / Edgelesskonsol A ( 0,40 : 1 ) fig 2...
  • Page 4 Overview / Översikt UK: insert corner pieces into the frame pie- ces. Remember to add the squared nuts into their slot before assembling all the corners. There should be two nuts for each bracket (in total 4pcs) in the top extrusion. If there is a center support there shall be one extra nut in both the top and bottom extrusions.
  • Page 5 UK: OPTIONAL Attach center support in top and bottom (fig Unroll the screensurface, viewing side down, on a clean and smooth surface. Put frame carefully on top. Frame corners shall reach surface edges (fig 7). Slide hook- fig 6 extrusions onto the screen surface (fig 8). Fasten hooks inte the groove (see fig 9).
  • Page 6 EN: Add bottom distance piece (see fig 10). SE: Montera den nedre distansen (se fig 10). fig 10...
  • Page 7 Wall mount / Väggmontering Wall bracket / Väggkonsol EN: USE FASTENERS INTENDED FOR THE ACTUAL SURFACE. Try to level them up as good as possible, using spirit level or laser fig 11 guide (fig 11). Sideways spacing isn’t crucial as they can slide sideways but we recommend that you try to even them out along the width.
  • Page 8 European Parliament and of the European Council concerning the Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH). All screen surfaces of Euroscreen ® projection screens are approved by the REACH regulation. ECHA European Chemicals Agency (ECHA) gathers information on the properties of manufacturers and importers chemical substances, which will allow their safe handling, and to register the information in a central database.
