1. 适用范围与用途/ Application scope
本断路器主要应用于交流 50/60Hz，工作电压至 AC380/400/415V，工作电流至 630A 的电路中作不频
繁转换及电动机不频繁起动之用。断路器具有过载、短路和欠电压保护功能，能保护线路及电源设备不受
损坏，同时还可以对过电流保护不能检测的长期存在的接地故障可能引起的火灾危险和人身触电提供保
护。
The breaker is mainly applied to infrequent changeover in a circuit with alternate current
of 50/60Hz, working voltage of AC380V/400V/415V and working current to 630A, and to the infrequent
start of electric motor. The breaker has overload, short circuit and undervoltage protection
functions that can prevent the line and power unit from being damaged while protecting the possible
fire danger and electric shock by the long-term failure of ground connection which fails to be
detected by overcurrent protection.
2. 型号说明/ Model and implication
ND M 2 L - □
1 2 3 4
序号 序号名称
SN SN name
企业代号 Enterprise code ND： "Nader"牌低压电器 ND: "Nader" low-voltage apparatus
1
产品代号 Product code
2
设计序号 Design SN
3
系列派生代号
4
Derived code of the
series
壳架等级
5
Shell frame level
分断能力级别
6
Breaking capacity level
操作方式
7
Operation mode
功能派生代号
8
Derived code of the
function
延时类型
9
Delay type
剩余电流脱扣器类型
10
Residual current release
type
极数 Number of poles
11
脱扣器代号 Release code 3：复式脱扣器 3: Complex tripper
12
附件代号
13
Accessory code
地址：上海市浦东新区申江南路 2000 号
文件编号：NDT2920129
□ □ / □
5 6 7 8
NDM2L
M：塑料外壳式断路器 M: Molded case circuit breaker (MCCB)
2
L: 剩余电流保护 L: Residual current protection
125、250、400、630
M：较高分断型 M: Relatively high breaking type
H：高分断型 H: High breaking type
无代号：手柄直接操作 No code: Direct handle-operated mode
P：电动操作 P: Motor-operated
Z：转动操作 Z: Rotary operation
无代号：AC 型漏电保护类型
No code: Type AC current leakage protection type
A：A 型漏电保护类型 A: Type A current leakage protection type
X：非延时 X: Non-time delay
Y：延时 Y: Delay
XI:非延时+报警不脱扣 XI: Non-time delay + alarm non-tripping
YI：延时+报警不脱扣 YI: Delay + alarm non-tripping
V：V 型剩余电流脱扣器 V: Type V residual current release
W：W 型剩余电流脱扣器 W: Type W residual current release
3, 4
参见表 1See Table 1
□ □ / □ □
9 10 11 12
