用途代号
14
Application code
4 极产品中 N 极
(中性极)形式
15
N-pole (neutral pole)
type of the 4P product
额定电流 Rated current
16
接线形式 Cabling type
17
注：
1、 操作方式为电动操作、手动操作时，剩余动作电流档位、剩余电流动作时间档位、漏电指示按钮无法调节；
2、 4 极 A 型产品不允许下进线。
Note:
1、 When the operation mode is electric operation or manual operation, the residual action current gear, residual current
action time gear, and leakage indication button can't be adjusted;
2、 Lower inlet wire not allowed for the 4P Type A product.
代号/Code 附件名称/Description of accessories
00
分励脱扣器/Shunt tripper
10
双辅助触头/Double auxiliary contacts
20
单辅助触头/Single auxiliary contact
21
欠电压脱扣器/Under-voltage tripper
30
分励脱扣器、双辅助触头/Shunt tripper, Double auxiliary contacts
40
分励脱扣器、单辅助触头/Shunt tripper, Single auxiliary contact
41
二组双辅助触头/Two groups of Double auxiliary contacts
60
二组单辅助触头/Two groups of Single auxiliary contact
61
双辅助触头、单辅助触头/Double auxiliary contacts, Single auxiliary contact
62
欠电压脱扣器、双辅助触头/Under-voltage tripper, Double auxiliary contacts
70
欠电压脱扣器、单辅助触头/Under-voltage tripper, Single auxiliary contact
71
报警触头/Alarm contact
8
双辅助触头、报警触头/Double auxiliary contacts, alarm contact
28
辅助与报警触头/Auxiliary and alarm contacts
58
双辅助触头、辅助与报警触头/Double auxiliary contacts /Auxiliary and alarm contacts
68
地址：上海市浦东新区申江南路 2000 号
文件编号：NDT2920129
无代号：配电型 No code: Power distribution type
A：N 极不安装过电流脱扣器，且 N 极始终接通
A: The N-pole isn't installed with an overcurrent release, but always
connected
B：N 极不安装过电流脱扣器，且 N 极与其他三极一起合分
B: The N-pole isn't installed with an overcurrent release, but on-off
with the other three poles
C：N 极安装过电流脱扣器，且 N 极与其他三极一起合分
C: The N-pole is installed with an overcurrent tripper, and on-off with
the other three poles
见表 2See Table 2
无代号：常规产品 No code: Normal product
P：联接排 P: Connection busbar
Z1：板后接线 Z1: Rear-plate connection
Z2H：插入式板后接线 Z2H: Plug-in rear-plate connection
Z2Q：插入式板前接线 Z2Q: Plug-in front-plate connection
Z3H：插入式板后接线一体式
Z3H: Integrated plug-in rear-plate connection
Z3Q：插入式板前接线一体式
Z3Q: Integrated plug-in front-plate connection
表
1/Table1
/
：附件代号/
Codes for accessary
