VERSION
# 20-02-25
1 / 9
MODEL #
CM7128CK/EK-VN
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7128CK-VN
Summary of Contents for Furniture of America CM7128CK-VN
- Page 1 MODEL # CM7128CK/EK-VN Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X 9...
- Page 5 CAL.KING BED E.KING BED CM7128CK/EK-VN #2 1pc #1 1pc #3 2pcs #4 8pcs Headboard Support leg Footboard Side Rail Ø5/16" 30X30X310mm #7 2pcs #5 1set #6 4pcs HB/FB Foot Support Rail Slat (13pcs) #A 8pcs #B 8pcs #C 8pcs Bolt Ø5/16"X1-1/2" Flat Washer Ø5/16"...
- Page 6 CM7128CK/EK-VN is packed in 3 cases Carton Disignation Part Hardware #A x 8pcs Headboard #Bx 8pcs #Cx 8pcs Support Leg #D x 1pc CM7128 CK/EK #E x 26pcs -HB-VN Slat (13pcs) HB/FB Foot CM7128 CK/EK Footboard -FB-VN Side Rail CM7128 CK/EK -R-VN Support Rail 6 / 9...
-
Page 7: Exploded View
Exploded View 7 / 9... - Page 8 ASSEMBLY INSTRUCTIONS Attach feet (#6) onto the headboard (#1). Attach feet (#6) onto the headboard (#2). Part #1 x1pc Part #2 x1pc Part #6 x4pcs Part #3 x2pcs Hardware #A x8pcs Hardware #B x8pcs Hardware #C x8pcs Align side rails (#3) to the headboard (#1) and footboard (#2), then secure by using bolts (#A) with washers (#B,C).
- Page 9 ASSEMBLY INSTRUCTIONS Part #4 x8pcs Part #5 x1set Part #7 x2pcs Align center slat (#7) to slats (#5), then secure by using support legs (#4). Adjust the levelers on the support legs (#4) according to ground level. Align slats (#5) to the side rails (#3), then secure by using screws (#E).
