ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7129Q
DIFFICULT
Page 1 of 6
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
(Included)
(Not Included)
Rev.16-08-05
Advertisement
Related Manuals for Furniture of America CM7129Q
Summary of Contents for Furniture of America CM7129Q
- Page 1 Assembly Instructions CM7129Q Tools Required For Assembly: ASSEMBLY RATING The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some...
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Finial Slat Page 3 of 6...
- Page 4 Before you begin,please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Align the right headboard leg (#4R) with the right side of the headboard (#1). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 5 Align the 2 finials (#5) onto the top of the headboard (#1). Secure two long screws (#E) through the holes on the headboard (#1) using a Phillips #E x 4 pcs screwdriver to tighten them #F x 2 pcs down to the 2 finials (#5). III.
- Page 6 Align the threaded end of the slat support leg (#7) with the pre-drilled holes of the slat (#6) and tighten by hand until secured. Repeat the process for the remaining 2 slat support legs (#7). onto the 2 slats (#6). Turnright(clockwise)totighten Turnright(clockwise)totighten #G x 6 pcs...
- Page 7 Assembly Instructions CM7129CK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 8 Page 2 of 6...
- Page 9 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Headboard Bolt 1/4”x2-1/2” #B x 8 pcs #2 x 1 pc Lock Washer Footboard...
- Page 10 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling of the product to avoid any potential injury and/or damage.
- Page 11 Align the 2 finials (#5) onto the top of the headboard (#1). #E x 4 pcs #F x 2 pcs Secure two long screws (#E) through the holes on the headboard (#1) using a Phillips screwdriver to tighten them down to the 2 finials (#5).
- Page 12 Align the threaded end of the 2 slat support legs (#7) with the pre-drilled holes of the slat (#6) and tighten by hand until secured. Repeat the process for the remaining 6 slat support legs (#7) onto the 3 slats (#6). Turn right (clockwise) to tighten #G x 8 pcs Turn right (clockwise) to tighten...
- Page 13 Assembly Instructions CM7129EK Tools Required For Assembly: ASSEMBLY RATING The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver (Not Included) products, two persons are recommended.
- Page 14 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 15 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Finial Slat Page 3 of 6...
- Page 16 Before you begin,please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Align the right headboard leg (#4R) with the right side of the headboard (#1). Prepare 8 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#A) and then the flat washer (#C) onto the SAME bolt (#A), in that order.
- Page 17 Align the 2 finials (#5) onto the top of the headboard (#1). Secure two long screws (#E) through the holes on the headboard (#1) using a Phillips #E x 4 pcs screwdriver to tighten them #F x 2 pcs down to the 2 finials (#5). III.
- Page 18 Align the threaded end of the 2 slat support leg (#7) with the pre-drilled holes of the slat (#6) and tighten by hand until secured.Repeat the process for the remaining 6 slat support legs (#7) onto the 3 slats (#6). Turnright(clockwise)totighten Turnright(clockwise)totighten #G x 8 pcs...
