Furniture of America CM7128CK-VN Assembly Instructions Manual

Hide thumbs Also See for CM7128CK-VN:

For more information contact our team: service.ec@foagroup.com

ASSEMBLY RATING

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

EASY

Assembly Instructions

CM7128CK/EK -VN

DIFFICULT

Tools Required For Assembly:

Allen Wrench

Phillips Screwdriver

2 PERSONS RECOMMENDED

Page 1 of 6

(Included)

(Not Included)

Rev: 1 9 - 01 -1 6

Table of Contents

Do you have a question about the CM7128CK-VN and is the answer not in the manual?

Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7128CK/EK -VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 8pcs #1 x 1pc Bolt Ø5/16" x 1-1/2" Headboard #B x 8pcs #2 x 1pc Lock Washer Ø5/16"...
Page 4 Exploded View Attach feet (#6) onto the headboard (#1). Page 4 of 6...
Page 5 Attach feet (#6) onto footboard (#2). Align side rails (#3) to the headboard (#1) and footboard (#2), then secure by using bolts (#A) with washers (#B,C). #A x 8pcs #B x 8pcs #C x 8pcs Page 5 of 6...
Page 6 Align center slat (#7) to slats (#5), then secure by using support legs (#4). Adjust the levelers on the support legs (#4) according to ground level. Align slats (#5) to the side rails (#3), then secure by using screws (#E). #E x 26pcs Page 6 of 6...

Cm7128ek-vn
