- Page 1 Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Operating instructions Rotation mixer AOX-S (110 V US-Version) Store the operating instructions readily available at the machine. Translation of original operating instruc- tions en - English, Rev. 3 - 2016 Art.no. 37125 Rev. 3...
-
Page 2: Control Elements
Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Control elements Bucket holding fixture Mixing tool motor Mixing bucket Suction nozzles for vacuum Belt eyelet Scraper KR mixing tool On/Off switch Mixing tool holding fixture Transport handle Swivel arm Mains plug Mixing tool KR (70151):... -
Page 3: Scope Of Delivery
Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Technical data: Large mixing bucket: 17 gal. Usable quantity: 10.5 gal. Rotary plate motor: 0.55 kW/0.75 hp / 110 VAC 60 Hz Mixing bucket speed: 18 rpm Mixing tool motor: 1.1 kW/1.36 hp / 110 VAC 60 Hz... -
Page 4: About This Document
You can find the safety information starting from page 5. Refer to the chapter intro- ductions and passages leading up to instructions for warnings. The copyright for images and texts remains with Collomix GmbH. You must read the operating instructions prior to initial commissioning. Observe the safety information. -
Page 5: Safety Information
X Only remove material samples with the device at a standstill. For your safety The AOX-S mixer was developed, produced and tested complying with the fundamental safety require- ments. Despite that, there are residual risks. • For this reason, read the operating instructions prior to operating the machine •... -
Page 6: Intended Use
Any other use of the machine or any use beyond this scope is considered unintended and thus improp- er. Safety and its protection can be impacted in this case. Collomix GmbH shall not be liable for any resulting damage. Intended use also includes: Compliance with all information in the operating instructions •... -
Page 7: Operation
Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Commissioning The device is delivered ready for operation in carton packaging. The net weight is 112.5 lb. The machine and power cable must always be checked for damage prior to commissioning. Check that the mixing tool is mounted correctly. -
Page 8: Troubleshooting
Repairs or functional faults to the electric system must only be carried out by authorised workshops. Worn mixing buckets should only be replaced with the Collomix original mixing bucket, Art. no. 60403. Correct functioning is only guaranteed with this bucket. -
Page 9: Warranty
Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Disposal The device, accessories and packaging should be disposed of in an environmentally friendly way. Do not dispose of in household waste. Electric devices do not belong in the household waste. Non-functional equipment can be recycled at public collection centres for electrical waste. - Page 10 Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Art.no. 37125 Rev. 3 Page 10...
- Page 11 Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Art.no. 37125 Rev. 3 Page 11...
- Page 12 Collomix GmbH Rotation mixer 85080 Gaimersheim AOX-S Manufacturer: Collomix GmbH Daimlerstraße 9 85080 Gaimersheim Germany Telephone: +49 (0)8458 3298-0 Fax: +49 (0)8458 3298-30 info@collomix.de www.collomix.com Made in Germany Art.no. 37125 Rev. 3...
