Operating Instructions
FORCED-ACTION MIXERS
COllOMATIC XM 2-650
COllOMATIC XM 3-900
Ref.no.: 39.014/015/016
(230 V / 400 V - EU)
Collomix Rühr- und Mischgeräte GmbH
Daimlerstraße 9
85080 Gaimersheim/Germany
Telefon: +49 8458 3298-0
www.collomix.com
Rev. 03-10
Force-action mixer
Collomatic XM
Page 1
Advertisement
Table of Contents
Related Manuals for Collomix Collomatic XM 2-650
Summary of Contents for Collomix Collomatic XM 2-650
-
Page 1: Operating Instructions
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM Operating Instructions FORCED-ACTION MIXERS COllOMATIC XM 2-650 COllOMATIC XM 3-900 (230 V / 400 V - EU) Collomix Rühr- und Mischgeräte GmbH Daimlerstraße 9 85080 Gaimersheim/Germany Telefon: +49 8458 3298-0 www.collomix.com... -
Page 2: Table Of Contents
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM Contents layout Technical data EC Declaration of Conformity Definitions of technical terms Safety instructions Responsibility of the user Intended use Liability and warranty Transportation instructions Delivery Moving the machine manually... - Page 3 Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM 1. Layout Key to illustration 1. Mixing tools 9. Carrier handles, lockable 2. Edge scraper 10. Cable connector 3. Guard hood 11. Control pin for the mixing tub 4. Latch bar 12.
-
Page 4: Technical Data
We declare herewith that this product conforms with the following standards and standard-setting documents: EN 12100, IEC 60745-1, EN 55014, EN 60204, EN 61000-4 in accordance with directives 2006/95/EEC, 2004/108/EEC, 2006/42/ EEC. Technical files at: Collomix Rühr- und Mischgeräte GmbH, Abt. Technische Entwicklung, Daimlerstr. 9, 85080 Gaimersheim, Germany Alexander Essing Collomix Rühr- und Mischgeräte GmbH... -
Page 5: Definitions Of Technical Terms
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM 2. Definitions of technical terms Direction of rotation This refers to the direction in which the gear unit and the mixing tools rotate under three-phase alternating current (400 V only). -
Page 6: Safety Instructions
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM 3. Safety instructions This machine has been manufactured in accordance with the latest approved rules of technical practice applicable at the time of its development and production, and is safe to use. -
Page 7: Responsibility Of The User
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM • Make sure that the control pin moves without hindrance at all times and that the limit switch also works properly at all times. It is imperative that these never become soiled. A malfunction here may cause the mixing tools to start up unintentionally. Risk of crushing! • If the machine is lifted by a crane or similar, the lifting ropes/cables or belts must only... -
Page 8: Intended Use
All essential warranty repair work must only be carried out by adequately trained service engineers or by third parties with express prior authorization from Collomix. The carrying out of unauthorized repairs may render the warranty null and void. -
Page 9: Transportation Instructions
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM 5. Transportation instructions 5.1 Delivery The machine is packed and delivered on a pallet. The machine has a net weight of 105 kg. The location of the machine’s center of gravity is shown in the adjacent illustration. -
Page 10: Trolley
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM 7.0 Trolley (accessory) The trolley (accessory) is designed for loading and unloading the mixing tub to and from the machine. At the same time the locking device on the trolley can be used to enable thin-bodied material to be poured out wherever it is required. -
Page 11: Handling
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM 7.3 Handling • Take hold of the trolley by both handles. • Move the two tub mounts under the tub and hook them both into the two recessed handles on the tub. • Press against the axle with one leg. Make sure that the tub is correctly in place. • Tilt the trolley towards you until you have the tub in balance. • If you are processing thin-bodied materials you can pour them by applying the locking device: • Pick up the tub as described above. Then set the trolley down lengthwise on the floor. The tub swings free. • First set the tub stop to vertical. The hook on the tub holder extends over the edge of the tub and holds it. -
Page 12: Mixing Tools
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM 8. Mixing tools Your forced-action mixer comes with three different mixing tools (Standard: universal mixing tools and a star-type mixing tool). These will enable you to mix materials of all viscosities. -
Page 13: Changing The Mixing Tools
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM If you are not going to replace the tool with another one, screw the threaded plug onto the threaded spindle to prevent it from getting soiled. Remember to take account of the different thread sizes, M 16 and M 18. -
Page 14: Using For The First Time
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM 11. Using for the first Time 11.1 Opening and closing the machine • Take hold of the handle and the latch bar. Pull them towards you. This opens the lock. • Pull the swivel arm upwards. • The machine now stands open in front of you. In the mixing tub you will find two open-ended wrenches and one other tool. Take these out and check that the tub is empty. -
Page 15: Setting The Timer Switch
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM 11.4 Setting the timer switch The timer switch is situated on the front panel of the machine. „90“ position The mixing tools run for 90 seconds before switching off automatically „180“... -
Page 16: Description Of The Safety Equipment
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM 12. Description of the safety equipment The safety devices previously referred to have been integrated in the machine for your personal safety and the safety of others. Make sure that these are in full working order at all times. -
Page 17: Troubleshooting
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM 13. Troubleshooting It is possible for faults to occur during use. The following checklist is intended to help you find the cause of each fault. All cases of electrical faults or major damage should only ever be rectified by a qualified expert. -
Page 18: Care And Maintenance
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM 14. Care and maintenance Follow these notes and instructions to ensure that your forced-action mixer machine has a long life and offers trouble-free service. Always pull out the power plug before carrying out any cleaning and maintenance work. -
Page 19: Annex
Collomix Rühr- und Mischgeräte GmbH Force-action mixer D-85080 Gaimersheim Collomatic XM 15. 1 Circuit diagram - 230 Volt, 50 Hz Collomatic XM 2-650 230V, 50 Hz 1 0 2 U < Circuit diagram - 400 Volt, 50 Hz Collomatic XM 2-650... -
Page 20: Exploded Drawing Of The Trolley
Collomix Rühr- und Mischgeräte GmbH Forced-action mixer D-85080 Gaimersheim Collomatic XM Page 20 Rev. 03-10 Ref.no.: 39.014/015/016...
