Collomix DUO Hand Mixer Quick Manual

Hand mixers
Motor Guard handle
Powerful and Multifunctional, this is for picking
long-lasting, up and putting down the machine
perfect for mixing with ease, and also protects against
break-age and dirt
Electronic speed controls
Infinitely variable for
Design
splash-free mixing
Attractive and
forward-looking
with unbreakable
and light housing
Safety lock-off
Safeguard for
unintentional
start-up
2-speed gear unit
Optimal power
utilization at slow
or fast rotating
speeds
Ergonomic grip
For comfortable and energy-saving working
M14 tool
connection
High-duty gear unit
For no-loss
Powerful and wear-resistant for optimum
power transmis-
power utilization and a long life
sion and quick
tool change-over
Which drive is best for mixing jobs:
If you want to use a power drill for mixing jobs, make sure that its motor is
powerful enough. The load exerted on the machine depends on the size of the
mixing attachment and the material to be mixed. Too big a mixing attachment
or too viscous a material will result far lower cooling of the drive motor and
the machine will burn out. For major mixing jobs it is always best to use a
suitable hand mixer.
Hand mixers
Model
CX 10 with WK 120
CX 10 with LX 120
Applications
WK 120 for cement, plaster,
ready-mixed mortar
LX 120 for paints, primer coats,
joint cement
Electronic machine with 1-speed gear
unit, exceptionally light, compact and
-30L
Elektronik
economical. Powerful and reliable, it is
ideal for mixing loads of up to approx.
30 liters. Infinitely adjustable speed
230V/4,4A
I: - 670min -1
1000W
control, with guard handle. Available in -120mm
110 V:800 W
230 V and 110 V!
Model
CX 20 with WK 120
CX 20 with LX 120
Applications
WK 120 for cement, plaster,
ready-mixed mortar
LX 120 for paints, primer coats,
joint cement
Mixer with 2-speed gear unit with infini-
tely adjustable speed control for hand-
ling the widest spectrum of mixing jobs
-40L
Elektronik
with professional ease. Rugged and
powerful, it is designed for universal use
for mixing loads of up to 40 liters. The
I: - 400min -1 230V/4,4A
II: - 700min -1 1000W
ideal tool for the finishing tradesman. -120mm
110 V:800 W
Available in 230 V and 110 V!
Hand mixers
Model
CX 40 with WK 140
CX 40 with MK 140
CX 40 with LX 150
Applications
WK 140 for cement, plaster,
ready-mixed mortar
MK 140 for mortar, screed,
quartz-filled material
LX 150 for paint, primer coats,
jointing cement
Universal professional mixer to satisfy
higher demands. Powerful motor,
-65L
Elektronik
2-speed gear unit, electronic speed
controls and rugged drive system for
reliable processing and a long useful
I: - 450min 230V/5,3A
-1
II: - 600min -1 1200W
life. Ideal for high-viscosity (semiliquid) -140mm
110 V:1200 W
mixing loads of up to 65 liters. Avail-
able in 230 V and 110 V!
Model
CX 60 with MK 160
Applications
MK 160 for mortars, screed,
quartz-filled material
The top-class machine for heavy-duty
and demanding professional applica-
tions. Featuring a 2-speed gear unit
-90L
Elektronik
and electronics, this is a highly power-
ful tool even in continuous use. The
champion among the professional tools
I: - 350min -1 230V/7,1A
II: - 500min -1 1600W
for tough daily use at the building site. -160mm
110 V:1400 W
Available in 230 V and 110 V!
DUO hand mixer
Designed for medium-sized loads, this
compact forced-action mixer is notable for
being a highly powerful and versatile tool;
easy to guide even in the most viscous of
materials; infinitely adjustable speed
controls; with HEXAFIX quick- action coup-
ling.
Art.No. Model
20.201 CX 22 DUO with MK 120 HF
44.070 1 set MK 120 HF
CX 22 DUO
I: - 400min -1 230V/ -50L
II: - 520min -1 1000W
DUO hand mixer
To help you master every material! This is a
powerful forced action mixer for the highest
of requirements; powerful and uncompromi-
sing in the material, it is comfortable to use
and takes the physical strain off the user;
infinitely adjustable speed controls; with
HEXAFIX quick-action coupling.
Art.No. Model
20.251 CX 44 DUO with MK 140 HF
44.080 1 set MK 140 HF
CX 44 DUO
I: - 350min -1 230V/ -90L
II: - 500min -1 1400W
TMS power mixer
Automatic compact mixer for standard
bags of mortar, adhesive, plaster, screed
and gravel concrete (-16 mm). Simple
operation, high mobility and perfect
mixing results are the attributes of this
unit. The finished mix is discharged
through the bottom opening into a wheel-
barrow or tub.
Maximum mixing volume: 80 liters
Drive: 2 kW, 230 V.
The right way to mix!
