ALLIANCE PRO/ALLIANCE PRO LT

HOWER

PLEASE REVIEW THIS ENTIRE MANUAL PRIOR TO INSTALLATION

Right side shower head installation shown as example

IMPORTANT!

DreamLine

reserves the right to alter, modify or redesign products at any time without prior notice for the

purpose of product improvement and customer experience. Please refer to the model's web page on

DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional

product details.

Do Not Return Product to the Store. Contact DreamLine® with any questions

ALLIANCE PRO/ALLIANCE PRO LT Shower Door Manual Ver 1 2/2021

OOR

NSTALLATION

Available in Shower and Tub Height. Installation methods are identical.

NSTRUCTIONS

Alliance Pro MODEL #s:

SDAL48W700

SDAL60W700

SDAL48W760

SDAL60W760

SDAL60W800

SDAL54W700

SDAL66W700

SDAL56W700

SDAL56W760

SDAL72W700

SDAT58W700

SDAL60W650

TDAL66W570

SDAT60W670

TDAL72W570

Alliance Pro LT MODEL #s:

SDAT48W700

SDAT60W700

SDAT54W700

TDAT60W550

SDAT56W700

TDAT60W570

SDAT58W700

TDAT60W600

SDAT60W650

TDAT60W620

SDAT60W670

Available in:

01 - Chrome

04 - Brushed Nickel

06 - Oil Rubbed Bronze

09 - Satin Black

Table of Contents

Need help?

Do you have a question about the ALLIANCE PRO SDAL48W700 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dreamline ALLIANCE PRO SDAL48W700

Page 1 ® purpose of product improvement and customer experience. Please refer to the model’s web page on DreamLine.com for the latest technical drawings, installation manuals, warranty information or additional product details. Do Not Return Product to the Store. Contact DreamLine® with any questions ALLIANCE PRO/ALLIANCE PRO LT Shower Door Manual Ver 1 2/2021 ©...
Page 2 Alliance Pro SKUs SDAL48W700VXX06 Alliance Pro SDAL56W760VXX09 Alliance Pro SDAL60W800VXX06 Alliance Pro SDAL48W700VXX04 Alliance Pro SDAL60W650VXX06 Alliance Pro SDAL60W800VXX04 Alliance Pro SDAL48W700VXX01 Alliance Pro SDAL60W650VXX04 Alliance Pro SDAL60W800VXX01 Alliance Pro SDAL48W700VXX09 Alliance Pro SDAL60W650VXX01 Alliance Pro SDAL60W800VXX09 Alliance Pro SDAL48W760VXX06 Alliance Pro SDAL60W650VXX09 Alliance Pro...
Page 3 Alliance Pro LT SKUs SDAT48W700VXX06 Alliance Pro LT SDAT60W650VXX06 Alliance Pro LT SDAT48W700VXX04 Alliance Pro LT SDAT60W650VXX04 Alliance Pro LT SDAT48W700VXX01 Alliance Pro LT SDAT60W650VXX01 Alliance Pro LT SDAT48W700VXX09 Alliance Pro LT SDAT60W650VXX09 Alliance Pro LT SDAT54W700VXX06 Alliance Pro LT SDAT60W670VXX06 Alliance Pro LT SDAT54W700VXX04 Alliance Pro LT SDAT60W670VXX04 Alliance Pro LT...
Page 4 For best results, squeegee the glass after each use and dry with a soft cloth. Record the following purchase information for your records or in the event you need to contact DreamLine ® Purchase Order...
Page 5: Table Of Contents
Table of Contents Section Title Page # Important Product Information Model Specific Preparation Tools Detailed Diagram of Alliance Pro/Alliance Pro LT Door Components Item List Installation Steps 8-20 Product Maintenance Troubleshooting Factory Parts Information 23-27 Symbol Legend Average Installation Time CORRECT - TIP - for ease of installation.
Page 6 • • DreamLine® reserves the right to alter, modify or redesign products any time without After opening all boxes and packages, read this introduction carefully. Check that all the prior notice for product improvement and customer experience. Please refer to the items are included in the package by marking off the components on the “Detailed...
Page 7: Model Specific Preparation
Before discarding the carton, check for small hardware bags that may have fallen to the bottom of the box. If any NOTE parts are damaged or missing, please contact DreamLine for replacement. The shipping ®...
Page 8: Tools
Tools Caulk gun with Phillips Flat-head 4-Foot Level Tape Measure Pencil clear, mold-resistant Screwdriver Screwdriver Silicone Drill Bit Drill Bit Ø7/32" Professional-grade Drill Bit Drill Bit Screw Gun Power Ø1/8" Ø9/64" (6mm) Ø3/16" Glass suction cup or Impact Driver Drill (3mm) (3.5mm) (4mm)
Page 10: Item List
Item List ALLIANCE PRO/ALLIANCE PRO LT Shower Door Manual Ver 1 2/2021...
Page 11 Item List ALLIANCE PRO/ALLIANCE PRO LT Shower Door Manual Ver 1 2/2021...
Page 12: Installation Steps
Locate and mark a center line on the threshold or tub deck. Fig 1a Extend the mark NOTE across to both walls. Center the bottoms of both Wall Profiles on the center line. Fig 1b Tools Needed © 2021 DreamLine® All Rights Reserved...
Page 13 Parts Needed Tools Needed Be sure all pilot holes are the correct size. Always use low torque and steady pressure when securing stainless steel screws to avoid stripping or breaking off the screw heads. © 2021 DreamLine® All Rights Reserved...
Page 14 Fig 3.4 The bumper slot for the Outside Door Glass (#10) faces the outside of the shower on the opposite Apply dish soap to the screw threads and use wall. Fig 3.5 a Phillips screwdriver to install screws to avoid stripping the screws © 2021 DreamLine® All Rights Reserved...
Page 15 (Or the Wall Profile on the shower head side) and mark NOTE 17.5” the center of the profile for (444mm) drilling. Drill a 7/32” (6mm) hole only through the Wall Profile (#01). Fig 3a Tools Needed Fig 3a © 2021 DreamLine® All Rights Reserved...
Page 16 Please skip this Step if installing any other Door Glass option. Install both Bumpers for S-Curved Glass (#04b) using the ST4.0 NOTE x 6mm Pan Head Screws (#16) Fig 3b Fig 3b Parts Needed Tools Needed © 2021 DreamLine® All Rights Reserved...
Page 17 Wall Profiles (L) - 1/16”(1.5mm) Underside of Bottom Profile Parts Needed Fig 4 Tools Needed Use a metal file to remove any burrs from the Guide Rail (#08) or Bottom Profile (#06) after cutting. © 2021 DreamLine® All Rights Reserved...
Page 18 Fig 5 Secure both sides with NOTE ST4.0 x10mm Screws (#07) Use a metal file to remove any burrs from the Guide Rail (#08) or Bottom Profile (#06) after cutting. Tools Needed Parts Needed © 2021 DreamLine® All Rights Reserved...
Page 19 (two holes) Fig 6b Tools Needed Right-side shower head installation shown as example Left-side shower head installation shown as example NOTE The same Door Glass con guration applies for the installation of S-Curved Door Glass. © 2021 DreamLine® All Rights Reserved...
Page 20 Cushion the underside of the glass and between the two glass doors. Be sure that both glass doors and Roller Wheels (#11) are oriented in the correct position for installation. Fig 7 Fig 7 Right-side shower head installation shown as example © 2021 DreamLine® All Rights Reserved...
Page 21 Do not set the glass down on any hard surfaces. Use a glass suction cup when moving glass and leave the corner protectors on the glass until Tools Needed necessary to remove them. Corner Protector © 2021 DreamLine® All Rights Reserved...
Page 22 Guide Rail (#08) at an inward angle and place the Roller Wheels NOTE (#11) into the inside track in the Guide Rail (#08). Allow both doors to hang freely and slide them both to one side of the shower. Fig 9 © 2021 DreamLine® All Rights Reserved...
Page 23 Roller Wheel down (lower in the slot) will raise the door glass. Fig 10 Lower Roller Wheel Raise Roller Wheel to raise Door Glass to lower Door Glass Tools Needed Fig 10 © 2021 DreamLine® All Rights Reserved...
Page 24 As an option, drill a Ø 1/8” hole through the Center Guide and into the Bottom Profile. Install a #6 x 3/8” Pan Head Screw (#07). Fig 11 Tools Needed Right-side shower head installation shown as example © 2021 DreamLine® All Rights Reserved...
Page 25 The provided Allen wrench can be inserted into the hole in the bolt head to help tighten the knob. Fig 12b x1 or 2 Fig 12b Tools Needed Right-side shower head installation shown as example © 2021 DreamLine® All Rights Reserved...
Page 26 Fig 13 Apply a quality, mold-resistant clear silicone Tools Needed to the entire interior perimeter of the shower NOTE door. Allow 24 hours for the silicone to set before using the shower. Fig 13 © 2021 DreamLine® All Rights Reserved...
Page 27: Product Maintenance
To maximize the life of your door, it is important to regularly inspect the glass and other hardware for misalignment, proper attachment, NOTE and/or damage. Contact DreamLine with any questions or concerns. ® Alliance Pro/Alliance Pro LT Maintenance Checklist ◻...
Page 28: Troubleshooting
Page(s) •Check all shipping/packaging material for missing parts/components. Missing Parts •If not found, contact DreamLine Customer Support [1-866-731- 2244] to order factory part replacement. •Check that the Inside Door Glass closes against the shower head side of the shower. •Check that the vinyl insert is installed properly in the Bottom...
Page 29 NOTES ALLIANCE PRO/ALLIANCE PRO LT Shower Door Manual Ver 1 2/2021...
Page 30 NOTES ALLIANCE PRO/ALLIANCE PRO LT Shower Door Manual Ver 1 2/2021...
Page 31 NOTES ALLIANCE PRO/ALLIANCE PRO LT Shower Door Manual Ver 1 2/2021...
