Aspley - Bunkbed Drawer
Assembly Instructions
Dimensions
Width - 52.9cm
Depth - 144.0cm
Height - 21.5cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, c a l l t h e
- Please keep for future reference
Customer Helpline: 03456 400 800
459/1261
457/9898
Issue 1 - 01/10/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Aspley 459/1261
Summary of Contents for Argos Aspley 459/1261
- Page 1 Aspley - Bunkbed Drawer Assembly Instructions - Please keep for future reference 459/1261 457/9898 Dimensions Width - 52.9cm Depth - 144.0cm Height - 21.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, c a l l t h e Customer Helpline: 03456 400 800 Issue 1 - 01/10/15...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not from natural timber; you may recommend the components and tools listed on pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below Drawer front ( 144.0 x 20.5cm) Drawer back ( 91.0 x 13.7cm) Drawer side x 2 ( 49.0 x 14.2cm) Support bar x 5 ( 48.7 x 7.0cm) Drawer base x 2 ( 138.7 x 24.3cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Locking nut x 8 Wooden dowel x 4 Metal dowel x 8...
- Page 5 Assembly Instructions Step1 insert wooden dowels into drawers sides Step2 Screw metal dowels into drawer front...
- Page 6 Assembly Instructions Step3 Screw metal dowels into drawer back Step4 Assembling drawer sides. Fit drawer sides drawer front Insert 2 locking nuts into each drawer side as shown. Use a screwdriver to turn locking nuts clockwise to lock.
- Page 7 Assembly Instructions Step5 Fit drawer back 2 to drawer sides, then insert locking nuts C into drawer sides as shown. Use a screwdriver to turn locking nuts clockwise to lock. Step6 Carefully, turn the product upside down. Fix wheels G using screws F . Leave 6cm distance from the drawer front and drawer back as shown.
- Page 8 Assembly Instructions Step7 With help, turn the other 1º way round. Fix support bars 4 using screws First, fix bars next to the drawer sides, leaving 2,5cm distance from drawer sides. Then, leave 24,7cm distance to fix the next bars and 24,7cm to fix the bar at the centre.
- Page 9 Assembly Instructions Step8 Place drawer bases the drawer as shown. Then, fix them through pre-drilled holes using screws Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800...
