Coway CHP-264L Manual

Hide thumbs

Advertisement

Table of Contents

Water Purifier CHP-264L (MY)
• This product can not be used if the voltage is different from that mentioned in the rating plate.
• For your safety and proper use of the product, please read this user manual before use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHP-264L and is the answer not in the manual?

Questions and answers

paul devadhas
March 31, 2025

hot water element not functioning

0
1 comments:
Mr. Anderson
March 31, 2025

To fix the hot water element not functioning on the Coway CHP-264L, follow these steps:

1. Turn on the Hot Water Function: Press and hold the Hot Water button for 2 or more seconds until the Hot Water indicator light turns on. Hot water will not dispense unless this is activated.

2. Wait for Heating: After turning on the hot water function, wait about 30 minutes for the water to heat up.

3. Check for Button Press: Ensure the Hot Water button is pressed before pushing the Cup-Touch Lever. Hot water will not dispense if the button is not pressed.

4. Restart the Unit if Needed:
- Unplug the power cord.
- Plug it back in.
- Turn on the water supply valve.
- Press the Hot Water button again for 2 or more seconds to reactivate.

If the problem continues, the issue may be electrical or internal, and professional service may be required.

This answer is automatically generated

0

Related Manuals for Coway CHP-264L

Summary of Contents for Coway CHP-264L

  • Page 1 Water Purifier CHP-264L (MY) • This product can not be used if the voltage is different from that mentioned in the rating plate. • For your safety and proper use of the product, please read this user manual before use.
  • Page 2 FEATURES Optimal size and elegant design This slim, elegant design fits into even narrow kitchen spaces, making it convenient to use. Energy-saving function using the light sensor When Eco mode is set, the motor and heater automatically run less often, reducing the amount of power consumed. Detachable water deco faucets The water deco faucets can be separated for easy cleaning (turn them clockwise to detach).

  • Page 3: Table Of Contents

    DEAR CUSTOMERS Coway Water Purifier Thank you for using Please read this user manual to use and maintain the product correctly. If you encounter a problem while using the product, you may solve the problem referring to the user manual.

  • Page 4: Safety Information

    SAFETY INFORMATION Be careful to keep this safety information. Please read this information to prevent property loss and ensure your safety. for 220 V - 240 V~, 50 Hz use only Danger : If you do not follow the instruction serious injury or even death could occur.
  • Page 5 • If the appliance produces a strange noise or odd smell, immediately unplug from the electrical outlet and call our Service Center. • Do not put the candle, or fire related objects on to the products. • Do not place any containers with water, medicine, food, small metallic objects, or any flammable material on the top of the product.

  • Page 6: Warning

    SAFETY INFORMATION Warning : If you don't follow the instructions serious injury or property damage could occur. • If the electric outlet is wet, carefully unplug the unit and let the electric outlet completely dry before subsequent use. • Unplug the product before repair, inspection, or parts replacement.
  • Page 7 Caution : If you don't follow the instruction minor physical injury or property damage may occur as a result . • The water purifier's installation shall comply with applicable state and local regulations. • Use after closing the water tank cover completely inside of the product.

  • Page 8: Parts Name

    PARTS NAME Front Function selection button and display Cold / Ambient water knob Hot Water Safety button Cold / Ambient water faucet Hot water faucet Hot water lever Cold / Ambient water lever Rear Grille Power cord Inlet(Orange) Outlet (Blue)

  • Page 9: Water Purification Process

    Using an uncertified filter or even using a certified yet expired filter may reduce filter performance. The 5-step water purification system (CHP-264L) STEP 1, 2 : PLUS NEO-SENSE FILTER This Plus Neo-Sense filter has the functions to remove particulates, dissolved organic and inorganic impurities.
  • Page 10 INSTALLATION PRECAUTIONS The instruction for the proper installation of the water purifier 1. Close main water supply valve to separate the faucet. 2. Apply the teflon tape on the adaptor and fit it to the pipe. Do not turn the water pipe. 3.
  • Page 11 Please check before use! This product is for 220 V - 240 V~, 50 Hz. Make sure to connect the power plug to a grounded 220 V - 240 V~, 50 Hz outlet. It requires a power supply to operate. •...
  • Page 12 BUTTONS AND INDICATORS Indication part 1 Hot Water Mode 2 Eco Mode 3 Low Water 4 Cold Water Indicator Indicator indicator Mode Indicator 5 Eco sensor Hot Water Mode Indicator Eco Mode Indicator The indicator lights up when hot The indicator lights up when Eco water is selected.
  • Page 13 Operation part Hot Water button Eco button Cold Water button Cold - Hot Water Ambient Safety Water button knob Hot Water button Eco button Use this to select/cancel selection Use this to select/cancel selection of the hot water function. of Eco Mode. Hold the button for 2 seconds or Hold the button for 2 seconds or more and the indicator lights up.
  • Page 14 BUTTONS AND INDICATORS ■ To use the Hot Water function Press the Hot Water button for 2 or more seconds and check that the Hot Water function is illuminated on the display and the Hot Water Temperature Indicator is illuminated. To turn off the Hot Water function, press the Hot Water button 2 seconds 2 seconds...
  • Page 15 HOW TO USE How to get cold water Press the Cold Water button and check that the Cold Water indicator is lit on the display. Turn the Cold Water - Ambient Water Knob to the right and push the touch lever. ▶...
  • Page 16 HOW TO USE How to get ambient water Turn the Cold Water - Ambient Water Knob to the left and push the Cup-Touch Lever. ▶ ▶ How to continuously extract ambient water Turn the Cold Water - Ambient Water Knob to the left and move the Cup-Touch Lever upward to lock the lever in place.
  • Page 17 How to get hot water Press the Hot Water Safety button and push the Cup-Touch Lever. Press the Hot Water button and check that the Hot Water indicator is lit. Push the Hot Water Safety button once more. ▶ - If hot water is not dispensed from the water purifier, check that the Hot Water indicator is lit up on the display (see p.

  • Page 18: How To Install

    HOW TO INSTALL Installation Guide Tap Water Supply Valve Only for 220 V - 240 V~, 50 Hz Inlet tubing (Orange) Outlet tubing(Blue) Connect the orange color inlet tubing to the tap water supplying pipe. Connect the outlet tubing Outlet tubing(Blue) Inlet tubing (Orange)
  • Page 19  Relocation and Installation When moving between locations, wait at least 30 minutes after installation to connect the power. To maintain optimal product performance, consult a Coway Technician for the detailed installation methods. Some residual water used during post-manufacturing inspection may be present in the filter.

  • Page 20: How To Clean

    HOW TO CLEAN How to Clean Inside Water Tank 1. Hold the cold water/hot water buttons at the front of the machine for 2-3 seconds each to turn it off and unplug the power cord. Lock the water supply valve. 2.
  • Page 21 5. Wipe the interior water tank surfaces with a soft cloth. 6. Rinse the interior water storage tank clean with water taken in advance from the machine, and then use the outlet tubing to completely drain. Run purified water through the product once and empty, and then use. 7.

  • Page 22: How To Clean The Product Body

    HOW TO CLEAN How to Clean the Tray 1. How to take out the tray The front of the tray can be easily separated by lifting it up slightly. 2. How to assemble the tray Slide the tray into the bottom of the product. Completely close the interior water storage tank cover.

  • Page 23: How To Clean The Deco Faucet

    How to Clean the Deco Faucet 1. Detach the deco faucet by turning it clockwise. 2. Rinse the deco faucet with water. 3. After rinsing, wipe the deco faucet with a soft, dry cloth. 4. Attach the deco faucet back by turning it counterclockwise after cleaning.

  • Page 24: Filter Replacement

    Please replace filters at a specified replacement cycle. For replacement filters, please contact Coway authorized dealers and distributors.  Filter replacement cycle If the filter is not regularly replaced, it may degrade the water quality from the product.

  • Page 25: How To Replace Filter

    HOW TO REPLACE FILTER Replace the filter! 1. Close the main water supply valve after unplugging the power cord, and drain the water inside of the water purifier. ▶ 2. Separate the fittings connected to the filter, and please replace with a new filter. (use the correct tool to remove the fittings).
  • Page 26 TROUBLESHOOTING The water purifier may operate abnormally because the user is unfamiliar with the product or due to some other reasons and not because of a product malfunction. In such a case, problems can be easily solved without the help from the service center by checking the following. If the problem is not solved after checking the following, please call the service center.
  • Page 27 Call center : 213-386-3033 Tel. : 041-850-7879 THAILAND MALAYSIA Add : Coway (Thailand) Co., Ltd. Add: Coway (Malaysia) Sdn. Bhd. 75/104-106 Ocean Tower 2 38th Fl, Soi Sukhumvit Level 20, Ilham Tower, No. 8, Jalan Binjai, 50450 Kuala 19 (Wattana), Sukhumvit Road, Klongtoey Nua, Lumpur.
  • Page 28 WATER FLOW DIAGRAM CHP-264L CHP-264L Disposed Water Valve (General) Storage tank Over FEED-NOS Heating VALVE Cooling Heating tank tank Hot Water Drain Cool/Ambient Water Water Feed Water Disposed Water...
  • Page 29 MEMO...
  • Page 30 MEMO...
  • Page 31 MEMO...
  • Page 32 1232535 www.coway.com...
