SKS Germany Mountain 11606 Manual

MANUAL BLADE SET COLOUR
SLIDE-ON FEATURE
SLIDE-ON FEATURE
SLIDE-OFF FEATURE
SLIDE-OFF FEATURE
2
1a 1e
3
4
5
EN . SHOCKBLADE
The dirtboard is a light dirtboard with maximum splash protection in all weather conditions. The flexible soft spoiler reliably keeps off rain and dirt even
under extreme track conditions. In order to ensure optimal performance, please refer to the installation instructions.

Fitting the cone:

The inside of the steering tube has to be clean and free of grease for fitting the adapter. If necessary, clean the underside of the steering tube.
1. Select the largest possible pair of expanding cones
- and secure with the screw
1a 1e
so that the unit can still be moved in the steering tube with slight pressure.
2. Tighten the screw
4
3. Align the adapter parallel to the track and make sure that the arrow on the adapter
4. Tightly fasten bolt
.
4

Fitting the dirtboard:

Push the dirtboard onto the adapter from the front until it clicks into place, keeping the quick-release button

Removing the dirtboard:

To remove, press the quick-release button

Safety note:

Regularly check that the adapter is securely mounted. Make sure that even when fully deflected, there is adequate clearance between the tire and the dirtboard and
between the dirtboard and the fork crown/booster.
¬ 11606 + 11607
Konus · cone diameter 1
Konus · cone diameter 2
Konus · cone diameter 3
Konus · cone diameter 4
Konus · cone diameter 5
that fits into the head tube. Fit the adapter
-
1a 1e
is used for mounting on thin fork crowns, while the adapter
and nut . The adapter
4 2 3a
and pull the dirtboard off to the front. The adapter remains firmly mounted on the steering tube.
5
¬
15 - 19 mm
¬
19 - 23 mm
¬
23 - 27 mm
¬
27 - 31 mm
¬
31 - 35 mm
or
3a 3b
points in the direction of travel.
or
3a 3b
depressed.
5
GERMANY
Wheel size | 26" + 27.5"
Tyre width | 3.0"
Weight | 101 g
ATTENTION
Mind the minimum
distance
!
between tyre at full
spring travel!
onto the pair of expanding cones
is for wide ones.
3b
MOUNTAIN
