Summary of Contents for SKS Germany COMPIT/E
- Page 1 G E R M A N Y COMPIT/E + COMPIT/E INSTRUCTIONS FOR USE LAST UPDATED 03.2019...
-
Page 3: Table Of Contents
Task and Function COMPIT/E COMPIT/E+ Technical Data Unpacking and Checking the Scope of Delivery Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar Requirement Disassembling the on-board computer from the bicycle Without COM/LIGHT With COM/LIGHT Mounting your smartphone on the COMPIT/E or COMPIT/E+ and removing it... -
Page 4: Information Concerning The Instructions And The Manufacturer
G E R M A N Y Information concerning the Instructions and the Manufacturer Information concerning the Instructions and the Manufacturer These instructions help you to use the “COMPIT“ and “COMPIT+“ product range safely. The COMPIT is a smartphone holder for smartphones. The COMPIT+ comprises the COMPIT and the +COM/UNIT. -
Page 5: Copyright
G E R M A N Y Information concerning the Instructions and the Manufacturer Copyright These instructions include information that is protected by copyright. These instructions are not to be co- pied, printed out, filmed, processed, duplicated or distributed in any form whatsoever, whether in part or in its entirety without prior written approval of SKS metaplast Scheffer-Klute GmbH. -
Page 6: Safety
Intended use The product is designed for private use. The COMPIT/E and COMPIT/E+ are used to mount a smartphone on an e-bike’s handlebar. They are only compatible with the Bosch Intuvia/Nyon on-board computer. They are intended for handlebars with the following diameters. -
Page 7: Basic Safety Instructions
➤ Only use authorised power adapters. ➤ Do not use the power adapter, the COMPIT/E, the COMPIT/E+ or the +COM/UNIT if they are damaged. ➤ Never open the +COM/UNIT’s housing. Always have repair work carried out by qualified specialists. ➤... -
Page 8: Design Characteristics Of The Warning Instructions
G E R M A N Y Safety Design characteristics of the warning instructions CAUTION Instructions with the word CAUTION warn of a situation that could result in slight or moderate injuries. Design characteristics of tips Tips provide additional information. -
Page 9: Description
G E R M A N Y Description Overview of the COMPIT/E’s scope of delivery Designation Clamping arms for COMPIT/E with adapter (R: right, L: left), 2x Docking station for mounting the smartphone with cover or the +COM/UNIT 3 mm Allen key COM/LIGHT adapter... - Page 10 G E R M A N Y Description Designation Locking washers for mounting the front light, 2x Shaft for affixing the front light The cover and the front light are not included in the scope of delivery.
-
Page 11: Overview Of The Compit/E+'S Scope Of Delivery
G E R M A N Y Description Overview of the COMPIT/E+’s scope of delivery Designation Clamping arms for COMPIT/E+ with adapter (R: right, L: left), 2x Docking station for mounting the smartphone with cover or the +COM/UNIT 3 mm Allen key +COM/UNIT... - Page 12 G E R M A N Y Description Designation Locking washers for mounting the front light, 2x Shaft for affixing the front light The cover and the front light are not included in the scope of delivery.
-
Page 13: Overview Of The Compit/E Without The Com/Light
G E R M A N Y Description Overview of the COMPIT/E without the COM/LIGHT Designation BIntuvia on-board computer (not included in the scope of delivery) Docking station for mounting the smartphone with cover or the +COM/UNIT Safety lever for locking the smartphone with cover or the +COM/UNIT... -
Page 14: Overview Of The Compit/E+ With Com/Light
G E R M A N Y Description Overview of the COMPIT/E+ with COM/LIGHT Designation Bosch Intuvia on-board computer (not included in the scope of delivery) USB cable for the power supplied by the e-bike battery Docking station for mounting the smartphone with cover or the +COM/UNIT... -
Page 15: Com/Light Overview
G E R M A N Y Description COM/LIGHT overview Designation Locking washer for mounting the front light Screws for mounting the front light (M4x8) Shaft for mounting the front light Screws for mounting the COM/LIGHT adapter (M5x16) -
Page 16: Com/Unit Overview
G E R M A N Y Description +COM/UNIT overview Designation Qi docking station (cableless charging) for mounting the smartphone with cover Button for switching on and off Docking station for mounting on the COMPIT Housing input (two contact pins in the housing) USB input USB output LED status indicator... -
Page 17: Led Status Indicator
G E R M A N Y Description LED status indicator + COM/UNIT STATUS INDICATES Battery indicator 4 orange LEDs flash +COM/UNIT is being in succession charged 1 LED illuminated 0 %–25 % battery capacity 25 %-50 % battery 2 LEDs illuminated capacity 3 LEDs illuminated 50 %-75 % battery... -
Page 18: Task And Function
Task and Function COMPIT/E The COMPIT/E is used to mount the smartphone on the handlebar of a bicycle equipped with a Bosch Intuvia/Nyon display. On the COMPIT/E, the smartphone can be mounted horizontally and vertically by turning it with an optional cover above the docking station. The smartphone on the COMPIT/E can be brought into the desired position by adjusting the tilt. -
Page 19: Technical Data
G E R M A N Y Description Technical Data +COM/UNIT Dimensions 130 x 70 x 21,5 mm Weight ~188 g USB input DC 5 V/2 A USB output DC 5 V/2 A Housing input DC 5–15 V/2 A Wireless transmission power Wireless efficiency >70% Operating frequency... -
Page 20: Unpacking And Checking The Scope Of Delivery
G E R M A N Y Unpacking and Checking the Scope of Delivery Unpacking and Checking the Scope of Delivery ➤ Remove the product from the packaging. ➤ Keep the original packaging in case you need to return the product to Customer Service. ➤... -
Page 21: Mounting The Compit/E And Compit/E+ On And Removing Them From The Bicycle's Handlebar
Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar Requirement You can affix the COMPIT/E and COMPIT/E+ on your bicycle if it meets the following requirements: Explanation On-board computer Type: Bosch Intuvia or Bosch Nyon... -
Page 22: Disassembling The On-Board Computer From The Bicycle
Mount the COMPIT/E or COMPIT/E+ and the on-board computer (1) on the bicycle as described on page 23 onwards. We have provided a description below of how to mount the COMPIT/E on the vehicle and remove it, both with and without the COM/LIGHT. The COMPIT/E+ is mounted on/removed from the bicycle in the same... -
Page 23: Without Com/Light
G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar Without COM/LIGHT ➤ Insert the rubber adapters (1) of the on-board computer into the clamping arms in the direction of the arrows as shown below. - Page 24 G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar ➤ Affix the e-bike’s on-board computer (2) and the COMPIT/E’s clamping arms (3) on the bicycle’s handlebar.
- Page 25 ➤ Mount the COMPIT/E on the handlebar with a torque wrench. To do so, tighten the screws (4) evenly (alternating between them) using the torque (1 Nm) indicated on the clamping arms. Proceed as follows to remove the COMPIT/E from the bicycle’s handlebar: ➤...
-
Page 26: With Com/Light
Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar With COM/LIGHT To mount the COMPIT/E with COM/LIGHT on the bicycle’s handlebar, you must first remove the do- cking station from the clamping arms without the COM/LIGHT adapter. Proceed as follows to do so: ➤... - Page 27 G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar ➤ Now affix the clamping arms (5) for the COM/LIGHT adapter on the docking station (4). ➤ Tighten the screws (3) slightly.
- Page 28 G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar ➤ Insert the rubber adapters (6) of the on-board computer into the clamping arms in the direction of the arrows as shown below.
- Page 29 G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar ➤ Now affix the on-board computer (7) and the COMPIT/E’s clamping arms (8) on the bicycle’s handlebar.
- Page 30 ➤ When mounting the COMPIT/E, tighten the screws evenly, alternating between them. ➤ Mount the COMPIT/E on the handlebar with a torque wrench. To do so, tighten the screws (9) evenly (alternating between them) using the torque (1 Nm) indicated on the clamping arms.
- Page 31 G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar ➤ Now affix the COM/LIGHT (12) on the COMPIT/E (10). ➤ Tighten the screws (11) slightly. The optional COM/CAM adapter can be mounted using the clamping arms in the same...
- Page 32 G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar Once you have mounted the COMPIT/E on the bicycle’s handlebar, you can affix a front light on the COM/ LIGHT. Proceed as follows to do so: ➤...
-
Page 33: Mounting Your Smartphone On The Compit/E Or Compit/E+ And Removing It
Insert your smartphone into the corresponding cover according to the relevant instructions. ➤ Place your smartphone on the COMPIT/E or COMPIT/E+ (as shown in 1 or 2) and turn it (about 45°) either to the right or left above the docking station until you hear it click into place. - Page 34 G E R M A N Y Mounting the COMPIT/E and COMPIT/E+ on and removing them from the bicycle’s handlebar Depending on how you turn it, your smartphone is mounted vertically (3) or horizontally (4). The safety lever (5) is locked.
-
Page 35: Adjusting The Inclination
G E R M A N Y Adjusting the Inclination Adjusting the Inclination You can move your smartphone into the desired position by adjusting the tilt on the COMPIT/E or COMPIT/E+. Proceed as follows to adjust the tilt: ➤ Press the smartphone (1) on the COMPIT/E or COMPIT/E+ downwards or upwards until you have reached the desired position. -
Page 36: Charging The Smartphone Via The +Com/Unit
+COM/UNIT. Proceed as follows in this regard: ➤ Ensure that the +COM/UNIT is sufficiently charged (min. 50%). ➤ Affix the +COM/UNIT on the COMPIT/E+ in the same way as the smartphone (please refer to page 33 regarding this matter). ➤ Press the button on the +COM/UNIT to switch it on. - Page 37 G E R M A N Y Charging the Smartphone via the +COM/UNIT Depending on how you turn it, your smartphone is mounted vertically (3) or horizontally (4). The bottom LED flashes blue. The smartphone is charging. ➤ To manually stop the charging process and switch off the +COM/UNIT without removing the smartphone from the +COM/UNIT, press the button for approx.
-
Page 38: Charging The Smartphone With A Cable
➤ Remove your smartphone from the +COM/UNIT by turning it (approx. 45°) above the Qi docking station. ➤ Press the safety lever and remove the +COM/UNIT from the COMPIT/E or COMPIT/E+ in the same way as the smartphone. ➤ Recharge the +COM/UNIT if necessary. Please refer to page 42 regarding this matter. -
Page 39: Using The Nfc
G E R M A N Y Using the NFC Using the NFC The +COM/UNIT is equipped with an NFC chip (NEAR FIELD COMMUNICATION). The NFC chip that is integ- rated in the +COM/UNIT can be put to various uses. The most diverse contents can be stored on the NFC chip it then being possible to read these out using an NFC-capable smartphone. -
Page 40: Charging The +Com/Unit And Your Smartphone Using Your E-Bike's On-Board Computer
Open the connection socket (1) of the e-bike’s on-board computer. ➤ Insert the plug (2) of the COMPIT/E+’s cable into the connection socket (1) of the e-bike’s on-board computer. The +COM/UNIT charging process starts straight after the e-bike has been switched on. The orange LEDs flash one after the other. - Page 41 G E R M A N Y Charging the +COM/UNIT and your smartphone using your e-bike’s on-board computer The smartphone cannot be continuously navigated with the e-bike if the +COM/UNIT is out of charge. The energy provided by the e-bike is too low to be able to navigate with the smartphone. The +COM/ UNIT’s battery indicator should show at least 50% charge to support the smartphone sufficiently during navigation.
-
Page 42: Charging The +Com/Unit
G E R M A N Y Charging the +COM/UNIT Charging the +COM/UNIT You can charge the +COM/UNIT as follows: ➤ Insert the plug of the USB cable that is included in the scope of delivery in the USB input port (1) and connect it with a suitable charger. -
Page 43: Troubleshooting
G E R M A N Y Troubleshooting Troubleshooting Sympton Cause Remedy The blue LED on the +COM/UNIT Error when charging the ➤ Remove your smartphone from is flashing fast. smartphone the +COM/UNIT and alter its position. When doing so ensure that your smartphone is positioned in the centre on the SKS logo. -
Page 44: Caring For The Product
G E R M A N Y Caring for the Product Caring for the Product Care for the product as follows: ➤ If necessary, clean the exterior of the product using a moistened cloth. -
Page 45: Accessories
G E R M A N Y Accessories Accessories Designation Order number Cover iPhone 6/7 /8 11538 Cover iPhone 6+/7+/8+ 11539 Cover iPhone X 11540 Cover SAMSUNG S7 11576 Cover SAMSUNG S8 11577 Cover SAMSUNG S9 11578 Cover HUAWEI P20 PRO+ 11579 Designation Order number... -
Page 46: Disposing Of The Product
G E R M A N Y Disposing of the Product Disposing of the Product In Germany ➤ Sort the product packaging and dispose of it accordingly. Make use of the local possibilities for the collection of paper, cardboard and lightweight packaging. ➤... -
Page 47: Warranty Declaration
(proof with the purchase receipt). Wearing parts are excluded – this especially being the +COM/UNIT battery unit. This is covered by a 6 months SKS GERMANY warranty. An incorrect handling or wrong use excludes a liability for defects. -
Page 48: Returns To Customer Service
G E R M A N Y Returns to Customer Service Returns to Customer Service Please take the following action as soon as you detect damage on the product: ➤ Please return the product to the following address in the original packaging and enclose a precise description of the damage: SKS metaplast Scheffer-Klute GmbH Zur Huberstushalle 4... - Page 52 G E R M A N Y...
