SKS Germany INFINITY UNIVERSAL Quick Start Manual

MANUAL ¬ INFINITY UNIVERSAL REARLIGHT
EN . Scope of delivery
A 1x
D 1x
B 1x
EN . Tools
EN
03
Fix the rear light bracket (A) to the
luggage rack with the washer (D)
and screw (E).
EN
04
Mount the rear light (F) on the luggage
rack using the loops from the rubber
band (B).
Please note. Ensure that the rubber
band is correctly seated.
B
F 1x
E 1x
C 1x
A
D
1.
E
2.
2x
1.
F
¬ 11948
EN . Mounting the rear light
EN
01
Thread the short rubber band (B) into
the holder (A) and position it over
the tabs on the back. Finally, fold the
loops of the rubber band (B) up and
down on the front.
A
EN
02
Place the rear light bracket (A) on
the mounted luggage rack. The bolts
of the bracket (A) must engage in
the holes of the luggage rack.
Please note. Note the alignment.
TX25
TOP
EN
i
Alternatively, you can mount the rear
light (F) directly on the seat post
using the long rubber band (C).
Please note. Seat post
diameter max. 31.8 mm.
3 Nm
3.
EN
i
Operation. To switch on and off,
press the button on the side for
approx. one second. You need a
micro-USB cable (not included in
scope of supply) for charging. The
charging time is approx. 2.5 hours.
1 x 1 sec. = ON
1 x 1 sec. = OFF
2.
GERMANY
ALLROAD
2.
1.
B
3.
1.
A
F
C
1.
1.
ROAD MOUNTAIN
4.
2.
< 31,8 mm
2,5 h
2.
