MANUAL ¬ AIRSPY TL
SAFETY INSTRUCTIONS
You must have read and understood the safety instructions provided
with your product before starting with the installation. Incorrectly installed
components present a considerable danger and can result in serious
injury and/or death. Please consult a qualified bicycle mechanic if you
have any questions concerning the installation of these components.
NOTE
Maintaining the correct tyre pressure has a huge impact on the service
life and safety of tyres. The AIRSPY provides support for the determina-
tion and monitoring of the current tyre pressure. The correct tyre pressure
depends on the model of tyre and can be read on the tyre or requested
from the manufacturer. Pumping up to the correct pressure range and
regular checking of the condition of the tyres is the responsibility of the
user. AIRSPY does not intervene actively in the driving process and can-
not correct fluctuations in tyre pressure (e.g. weather related). AIRSPY
will only work correctly if there is adequate battery capacity and use is
appropriate.
Do not use a high-pressure washer. Do not use any acidic or degreasing
agents. Chemical cleaning agents and solvents can permanently dam-
age components.
WARNING
!
Batteries must not be burnt under any circumstances. Do not use any
sharp or conductive objects to prise out the battery. Keep the battery out
of the reach of children. Never put the battery in your mouth. You must
consult a doctor immediately if you swallow the battery. The battery must
not be dismantled, damaged or pierced. Please contact the battery man-
ufacturer if you have any questions about the safe handling of batteries.
SIMPLIFIED EU DECLARATION OF CONFORMITY
The simplified EU declaration of conformity according to Article 10 (9) is
indicated as follows:
SKS GERMANY hereby declares that the AIRSPY radio system
mentioned in these instructions complies with regulation 2014/53 / EU.
The full text of the EU declaration of conformity is available
on the following website:
www.sks-germany.com/service/downloads
1.1 Taking into operation
Open the battery compartment and remove the protective strip.
Insert the battery and lock the battery cover in place.
1.2 Make a note of the serial number
123456
VORNE/FRONT
¬ 11757 + 11770 + 11857 + 11858
D = 6,5
A
60
67
74
81
H

2. Valve installation

Insert the valve into the valve hole.
Check the tubeless sealing tape for damage.
Hold the valve and put on the 1st seal.
check
D
D = 8,5
H
18-25
>25-32
>32-39
>39-46
A
!
!
GERMANY
ALLROAD

1. preparing the AIRSPY

1.1 dismantling the valve

Release the valve cap and securing nut from the AIRSPY valve and pull
the valve adapter away from the AIRSPY housing.
Hold the valve and attach the sensor housing. Serial number points to the
wheel hub. Lightly lubricate the O-rings if necessary.
!
S/N
x2345x
TOP
Hold the valve and put on the 2nd seal.
MOUNTAIN
