MikroTik 5GHz RouterBOARD Series Quick Manual

EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v6.49.1 or the latest stable version, to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik devices must be installed according to instructions.
This "5GHz RouterBOARD" series Quick Guide covers models: RB911G-5HPnD, RB912UAG-5HPnD, RB922UAGS-5HPacD, RB911G-5HPacD, RB911-5HnD
(911 Lite5), RB911-5HnD (911 Lite5 dual), RB911-5HacD (911 Lite5 ac).
This is a network device. You can find the product model name on the label (ID).
Please visit the user manual page on
Technical specifications, brochures, and more info about products at
The most important technical specifications for this product can be found on the last page of this Quick Guide.
Configuration manual for software in your language with additional information can be found
If you need help with configuration, please seek a
Depending on the antenna used, you must set its gain to ensure that EIRP meets the limit set by the local authorities. This is done in the Quickset menu.
This Device accepts input of 24V DC power adapters. This Device can be powered via a DC jack.
First Use:
This product comes without enclosure and is designed to be installed into the users' end products or enclosures. Compatible MikroTik enclosure for this
product can be found at https://mikrotik.com/products/group/enclosures
The device comes in ESD protective packaging. When handling electrical equipment please observe the following safety precautions;
Use a wrist grounding strap when unpacking and working with electrical components to avoid electrical discharge (ESD) damage;
After unpacking please place the router on the anti-static mat;
When mounting the unit make sure there are no objects that can damage or touch the PCB plate;
The device can be mounted in your desired location using the factory provided holes in a PCB plate, located on each side of the device;
Connect the device to the PoE injector with an Ethernet cable;
Connect the PoE injector into the PC;
Connect the power adapter to the PoE injector;
Download WinBox configuration tool
Open WinBox and connect to the device;
Default IP: 192.168.88.1, user name:
Download the latest RouterOS software from
Choose MIPSBE packages and save them to your PC;
Open WinBox and upload downloaded packages, drag and drop into any windows;
Restart the device;
Connect again and in the QuickSet
Secure your device and set a strong password.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
The product comes without enclosure and is meant to be installed into the enclosure by trained and qualified personnel. The installer is responsible for making
sure, that the Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
Please read the mounting instructions carefully before beginning installation. Failure to use the correct hardware and configuration or to follow the correct
procedures could result in a hazardous situation for people and damage to the system.
Keep this device away from water, fire, humidity, or hot environments.
Use a wrist grounding strap when unpacking and working with electrical components to avoid electrical discharge (ESD) damage. After unpacking please
place the router on the anti-static mat. When a mounting unit makes sure there are no objects that can damage or touch the PCB plate.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
Exposure to Radio Frequency Radiation:
uncontrolled environment. This MikroTik device should be installed and operated no closer than 330 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039
BG - Български. Бързо ръководство:
Това устройство трябва да бъде надстроено до RouterOS v6.49.1 или най-новата стабилна версия, за да се гарантира спазването на местните
наредби!
Крайните потребители са отговорни да спазват местните разпоредби, включително работа в рамките на законни честотни канали, изходна
мощност, изисквания за окабеляване и изисквания за динамичен избор на честота (DFS). Всички устройства на MikroTik трябва да бъдат
инсталирани съгласно инструкциите.
https://mt.lv/um for the full up-to-date user manual. Or scan the QR code with your mobile phone.
consultant https://mikrotik.com/consultants
https://mt.lv/winbox ;
admin , no password, or use
https://mikrotik.com/download
menu set your Country, to apply country regulation settings;
This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
https://mikrotik.com/products
at https://mt.lv/help
Neighbors tab and connect with MAC address;
;
