Step 11: Assemble the Awning to the Front Wall. The top of the Awning is the side that
has five lines formed in it (Fig. 11a). Fold both ends of the Awning down 90 degrees (Fig.
11b). Insert the Awning into the opening above the door of the Front Wall at an angle
(Fig.11c).
Top side
of Awning
Fig. 11a
Once the slot on the Awning is aligned with the tab on the Front Wall (Fig. 11e),
pull up on the Awning until the tab is in the slot (Fig. 11f). Now the tabs on each
end of the Awning should align with the two small slots on the Front Wall. Rotate
the Awning down, snapping the two side tabs into place. (Fig. 11d)
Fig. 11e
Awning Assembly
Fig. 11b
Fig. 11f
Fig. 11c
Fig. 11d
