Formex Snap Lock Chicken Coops Assembly Instructions Manual page 5

Step 2: Assemble the Front Wall to a Nest
Side Wall by aligning, and then inserting the
tabs on the Nest Side Wall into the slots of the
Front Wall. (Fig.2a)
Please note the difference be-
tween what the exterior of the
walls look like and what the interi-
or of the walls look like. Vertical
lines and hardware face out.
This is what the interior of
the walls look like. (Fig.2b)
Fig. 2b
Step 3: Assemble the Front Wall to the oth-
er Nest Side Wall by aligning, and then insert-
ing the tabs on the Nest Side Wall into the
slots of the Front Wall. (Fig. 3)
Step 4: Assemble the two Nest Side Walls
to the Back Wall by aligning, and then insert-
ing the tabs on the Nest Side Walls into the
slots of the Back Wall. (Fig. 4)
Coop Wall Assembly
Fig. 3
Fig. 2a
Fig. 4
