GF 0252 Configuration Tool
*3-0252.090*
3-0252.090
Rev. 3 01/22
•
English
•
Deutsch
•
Français
Español
•
•
中文
中文
Description
The 0252 Configuration Tool is a USB to Digital (S
Microsoft
Windows
compatible software program used for interfacing with
®
®
GF 9900 Transmitters and blind sensors via a computer.
The 0252 tool and software allows the user to:
•
Set application parameters (Engineering units, 4 to 20 mA span, etc.)
•
Save the setting configuration data to a computer file.
•
Upload a previously stored configuration data file into the GF product.
•
Monitor a sensor's performance and log the data to a file.
•
Reset the product settings to factory default condition.
•
Calibrate 258X FlowtraMag Full Bore Magmeter, 2610 Dissolved Oxygen
Sensor and pH/ORP sensors using the 2751 Smart Sensor Electronics.
Table of Contents
Warranty Statement ................................................................................ 2
Product Registration ............................................................................... 2
Safety Information ................................................................................... 2
Specifications .......................................................................................... 2
Required Equipment ............................................................................... 3
Install Software ....................................................................................... 3
Run Software .......................................................................................... 3
Set Software Language .......................................................................... 3
Sensor Wiring (2250, 2350, 2450, 2750, 2751) ...................................... 4
2551 Wiring ............................................................................................. 5
2552 Wiring ............................................................................................. 5
258X Wiring ............................................................................................ 6
2610 Wiring ............................................................................................. 6
9900 Wiring ............................................................................................. 6
General Software Operation ................................................................... 7
Sensor Operation .................................................................................... 8
2551 & 2552 Operation ........................................................................... 9
258X Operation ..................................................................................... 11
258X Calibration ................................................................................... 13
2610 Operation ..................................................................................... 15
2610 Calibration .................................................................................... 16
2751 Operation ..................................................................................... 17
2751 Calibration .................................................................................... 19
9900 Operation ..................................................................................... 22
Datalogger Operation............................................................................ 24
Ordering Information ............................................................................. 24
Microsoft and Windows are registered trademarks of Microsoft Corporation
in the United States and other countries.
Operating Instructions
L) convertor and
3
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GF 0252
Summary of Contents for GF 0252
-
Page 1: Table Of Contents
English GF 0252 Configuration Tool *3-0252.090* 3-0252.090 Rev. 3 01/22 Operating Instructions Description The 0252 Configuration Tool is a USB to Digital (S L) convertor and Microsoft Windows compatible software program used for interfacing with ® ® GF 9900 Transmitters and blind sensors via a computer. -
Page 2: Warranty Statement
All warranty and non-warranty repairs being returned 2751, and 9900 Transmitter must include a fully completed Service Form and goods must be returned to your local GF Sales office Operating System ....Windows 7 (32 and 64 bit), or distributor. -
Page 3: Required Equipment
Help menu, then clicking on About. Set Software Language The 0252 software saves your language preferences. Each time the software is launched, the previous language selection will be used. English is the default language. 1. Click on the File menu in the upper left. -
Page 4: Sensor Wiring (2250, 2350, 2450, 2750, 2751)
Windows PC GF 2450 Pressure Sensor White Black Data Data Black +5V out +5V out White Windows PC Windows PC GF 2750/2751 Submersible Electronics with pH/ORP Sensor White White Black Data Data Data Black Black +5V out +5V out +5V out... -
Page 5: 2551 Wiring
CAUTION! 24 VDC Do not connect power directly to the 0252 Configuration Tool. Black Improper power supply wiring can cause damage to the 0252 hardware and computer. Turn 24 VDC Power OFF when wiring the magmeter. White Data 2552 Magmeter Wiring... -
Page 6: 258X Wiring
Refer to the Direct Conductivity/Resistivity Module Instruction Sheet for instructions. 1. Disconnect power on the 9900. 2. Unplug the sensor connector from the S L/Frequency input jack on the 9900 and connect the 0252 Tool in its place. 3. Reconnect power to the 9900. SHLD... -
Page 7: General Software Operation
NOTE: This will overwrite any changes made in the 0252 software since the last Write. Write Applies the data entered in the 0252 software to the connected device. Once you have entered the desired setting changes in the software screens, press Write to load your new settings onto the connected device. -
Page 8: 2551 & 2552 Operation
5. Click “Read” to confirm * NOTE: A proper re-span of the 4 to 20 mA Loop will also require the correct internal pipe ID and K-factor, as both are used to find the effective velocity of the pipe. GF 0252 Configuration Tool... - Page 9 Set the flow rate where all Magmeter outputs will be forced to zero. Low Flow Cut Off When the flow rate is at or below this value, the frequency output will be 0 Hz and the current output will be 4 mA. GF 0252 Configuration Tool...
-
Page 10: 258X Operation
Select Output modes, 4 to 20 mA as either Active or Passive, S³L or Frequency output. Note: Setting the 258X to frequency will prevent the use of the 0252 tool. You will need to change the 258X back to S³L using the Android or iOS app before using the 0252 software. - Page 11 258X Operation GF 0252 Configuration Tool...
-
Page 12: 258X Calibration
Cancel Flow Rate Calibration and return to Calibration screen Volumetric settings: Start Volumetric Calibration Stop Volumetric Calibration after the desired Volume has passed Enter Volume and click Set Volume to Calibrate Cancel Volumetric Calibration and return to Calibration screen GF 0252 Configuration Tool... - Page 13 258X Calibration GF 0252 Configuration Tool...
-
Page 14: 2610 Operation
Select Measurement, Dissolved Oxygen or Temperature, for 4 to 20 mA Output Set 4 mA Set Point Set 20 mA Set Point Information: Read Only, Sensor Serial Number - Click Read to Update Read Only, Sensor Cap Expiration Date, for 3-2610-41 - Click Read to Update GF 0252 Configuration Tool... -
Page 15: 2610 Calibration
With probe in 0% Saturated Water click Start to begin the second point Calibration Once probe reading is stable click Finish to complete calibration Reset Calibration: Click Reset Cal to reset the DO calibration to Factory Default GF 0252 Configuration Tool... -
Page 16: 2751 Operation
Usage Time (pH or ORP) Minimum pH/mV (pH or ORP) Maximum pH/mV (pH or ORP) Minimum Temperature (pH) Maximum Temperature (pH) Click to Measure Glass Impedance (pH) Click to Measure Junction Impedance (pH or ORP 276x Only) GF 0252 Configuration Tool... - Page 17 2751 Operation GF 0252 Configuration Tool...
-
Page 18: 2751 Calibration
Wait for reading to stabilize then Click Continue (pH) To cancel calibration click Cancel and return to Calibration Screen (pH) Enter Temperature Value Click End to complete Temperature Calibration (pH) To cancel calibration click Cancel and return to Calibration Screen (pH) GF 0252 Configuration Tool... - Page 19 2751 Calibration GF 0252 Configuration Tool...
- Page 20 2751 Calibration GF 0252 Configuration Tool...
-
Page 21: 9900 Operation
4. Press ► to edit REMOTE SETUP. If required, enter the security code. 5. Press ▲ to change the flashing NO to YES. Press ENTER to confirm change. 6. REMOTE SETUP should be flashing, indicating the 9900 is ready for communication with the 0252 Tool. Set Instrument Type:... - Page 22 9900 Operation (General Software Operation, pg. 7) GF 0252 Configuration Tool...
-
Page 23: Datalogger Operation
Datalogger Operation The 0252 can serve as a field data logger to download data directly into a *.csv (Comma Separated Value) file. NOTE: The 0252 does NOT have internal memory to store data. It must be connected to a computer to use the datalog function. -
Page 24: Ordering Information
For Worldwide Sales and Service, visit our website: www.gfps.com • Or call (in the U.S.): (800) 854-4090 For the most up-to-date information, please refer to our website at www.gfps.com 3-0252.090 Rev. 3 01/22 English © Georg Fischer Signet LLC 2022...
