- Page 1 Model 13P Single-Stage Piston ® Compressor Manual Specifications • Installation • Assembly American Eagle 740 North State Street PO Box 169 Garner, IA 50438 800-392-3015 Subject to Change without Notification. Rev 1 www.americaneagleacc.com © 2019 American Eagle PN 92580...
- Page 2 H YDRA U LIC FLO W ( GP M) H Y DRAUL I C P R E SS URE (PS I ) CO MP RESS OR SPE ED ( RPM ) MADE IN THE U.S.A. BY AMERICAN EAGLE. PN 54490 Page ii | American Eagle 13P Compressor Manual ®...
-
Page 3: Table Of Contents
Typical Hydraulic Circuit for Tandem (Two Part) Pump ..............9 Typical Hydraulic Circuit for Compressor with Auxiliary Cooler ............10 Chapter 3 - Assembly Drawings ......................11 13P Assembly - PN D1829 ........................11 Crankcase Group (Straight Shaft) ...................... 12 Cylinder Group ............................. 13 Head Group ............................ -
Page 4: Introduction
This manual is not binding. American Eagle reserves the right to change, at any time, any or all of the items, components, and parts deemed necessary for product improvement or commercial/production purposes. -
Page 5: Chapter 1 - Specifications
16.69" Electrical 12V DC Crankcase Oil Capacity 24 Ounces Cooler Fan 350 CFM, 12 Volt (Pull) Drive Type Direct Driven NOTICE Duty cycle on Piston Compressors is 50:50 over 10 minutes. American Eagle 13P Compressor Manual | Page 1 ®... - Page 6 This page intentionally left blank. Page 2 | American Eagle 13P Compressor Manual ®...
-
Page 7: Chapter 2 - Installation
Procedure: Assemble rod onto the crankshaft taking care to align the machined surfaces together and tighten cap screws finger tight. Tighten bolts until hand tight and torque to 18 ft-lbs. Check twice the torque reading before final assembly of the cylinders. American Eagle 13P Compressor Manual | Page 3 ®... -
Page 8: Component Installation, Continued
CPRSR RELAY (12V CONTROL INPUT) * CUSTOMER ADDED WIRING MUST MATCH OR YEL 14GA SPEED CTRL EXCEED PIGTAIL WIRE SIZE FOR POWER (12V CONTROL OUTPUT) SUPPLY AND GROUND CIRCUIT BLK 12GA GROUND Page 4 | American Eagle 13P Compressor Manual ®... -
Page 9: Electrical Schematic
12V power supply. The yellow wire is required from the compressor when connecting the speed control into the system. LINE CPRSR MOTOR SPD CTRL PRESSURE SWITCH HYDRAULIC MANIFOLD COMPRESSOR (12V INPUT) GROUND SPEED CONTROL American Eagle 13P Compressor Manual | Page 5 ®... -
Page 10: Hydraulic System
The airline is routed using a ¾” 200 psi air/steam hose. This delivery line should be free from all obstructions. Note: There should be no check valve installed between the compressor and the air tank (One is already included in the compressor package). American Eagle recommends the installation of a ten-gallon air tank (minimum) to maintain proper operation of the air compressor. -
Page 11: Compressor Pressure Switch
2. After kick out pressure is set, adjust the kick on screw setting to 115 psi minimum/120 psi maximum. 3. Cycle compressor to verify correct settings. 4. For questions about this procedure, please contact American Eagle Customer Service at 800-321-3741. American Eagle 13P Compressor Manual | Page 7 ®... -
Page 12: Typical Hydraulic Circuit For Single-Section Pump
PN 30533 Typical Hydraulic Circuit for Single-Section Pump Page 8 | American Eagle 13P Compressor Manual ®... -
Page 13: Typical Hydraulic Circuit For Tandem (Two Part) Pump
Typical Hydraulic Circuit for Tandem (Two Part) Pump American Eagle 13P Compressor Manual | Page 9 ®... -
Page 14: Typical Hydraulic Circuit For Compressor With Auxiliary Cooler
Typical Hydraulic Circuit for Compressor with Auxiliary Cooler HYDRAULIC RESERVOIR FILTER FILTER SCREEN AUXILIARY COOLER SUCTION PORT SINGLE HYDRAULIC PUMP COMPRESSOR RETURN PRESSURE Page 10 | American Eagle 13P Compressor Manual ®... -
Page 15: Chapter 3 - Assembly Drawings
41 D1264 FTG 0.75-CLOSE RED BRASS NIPPLE 0347 NUT 0.38-16 HH NYLOC 0340 WASHER 0.25 FLAT 5480 VALVE CHECK 0.75 STANDARD 0521 WASHER 0.25 LOCK 43 C6101 FTG 4-2 MP-MP HEX NIPPLE American Eagle 13P Compressor Manual | Page 11 ®... -
Page 16: Crankcase Group (Straight Shaft)
Crankcase Group (Straight Shaft) CRANKCASE GROUP Page 12 | American Eagle 13P Compressor Manual ®... -
Page 17: Cylinder Group
C6360 CYLINDER V480 FINISHED O/S C0922 CAP SCR 0.31-18X1.00 HHGR5 5827 RING OIL V480/200 FLEX DIVIDER 32931 RING SCRAPER V480/200 H#48638 32930 RING CPRSN V480/200 BARREL H#38347 36368 RING OIL V480/200 RING RAIL American Eagle 13P Compressor Manual | Page 13 ®... -
Page 18: Head Group
Head Group HEAD GROUP Page 14 | American Eagle 13P Compressor Manual ®... -
Page 19: Chapter 4 - Replacement Parts
Embedded Filter Screen C0296 Embedded Filter Foam - Outer C0715 Embedded Filter Foam - Inner C0294 Embedded Filter Retainer C0087 Synthetic Compressor Oil (Quart) 7259 Synthetic Compressor Oil (Case of 12 Quarts) American Eagle 13P Compressor Manual | Page 15 ®... - Page 20 ® Subject to Change without Notification. © 2019 American Eagle...
