For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3712PT-5PK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 8
(Included)
Rev: 19-07-11
Advertisement
Related Manuals for Furniture of America CM3712PT-5PK
Summary of Contents for Furniture of America CM3712PT-5PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3712PT-5PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 8...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 16pcs Table Top Bolt Ø5/16" x 3-1/4''L #2 x 4pcs #B x24pcs Table Leg Bolt Ø5/16"...
- Page 4 Exploded View Align table legs (#2) to the table (#1), then secure by using bolts (#B) with washers (#E,F). # B x 8pcs #E x 8pcs #F x 8pcs Page 4 of 8...
- Page 5 Align seat (#3) to the chair back (#4), then secure by using bolts (#C) with washers (#E,F). # C x 2pcs #Ex 2pcs #F x 2pcs Secure corner holes of the seat (#3) to chair back (#4), then secure by using bolts (#A) with washers (#E,F). # A x 4pcs #E x 4pcs #F x 4pcs...
- Page 6 Align stretchers (#8,9) to chair back (#4) as shown in the diagram. Align front stretcher (#7) to the front legs (#5,6) as shown in the diagram. Page 6 of 8...
- Page 7 Align front legs (#5,6) to seat (#3), while have stretchers (#8,9) connect to front legs (#5,6). Secure stretchers (#7,8,9) by using screws (#D). # D x 6pcs Page 7 of 8...
- Page 8 Secure front legs (#5,6) to seat (#3) by using bolts (#B) with washers (#E,F). #B x 4pcs #E x 4pcs #F x 4pcs ASSEMBLY IS COMPLETED Page 8 of 8...
