VERSION # 20-06-16
1 / 8
MODEL #
CM3774T
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America Atenna I CM3774T
Summary of Contents for Furniture of America Atenna I CM3774T
- Page 1 MODEL # CM3774T Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 8...
- Page 5 DINING TABLE CM3774T PARTS #1 1pc #2 1pc #3 1pc #4 1pc Glass Top Leg A Shelf B Base HARDWARE #A 12pcs #B 4pcs #C 16pcs #D 16pcs Bolt ∅ 5/16" x 1-1/4" Bolt ∅ 5/16" x 3/4" Flat Washer ∅ 5/16" Lock Washer ∅...
- Page 6 CM3774T Points 2 cartons Carton Designation Part Hardware CM3774T-1 Table Top 12pcs Leg A 4pcs 16pcs CM3774T-2 Leg B 16pcs Base 6 / 8...
- Page 7 Using the Allen wrench (#E) remove each bolt assembly, then remove the bracket (#F). Note, keep the bolt assembly parts together. 2. Re-align the bracket (#F), then insert the bolt assemblies and secure using the Allen wrench. Part Part Hardware 1.
- Page 8 Part Hardware Hardware Hardware 1. Prepare 6 bolt assemblies by first inserting a lock washer (#D) onto the bolt (#A) then a flat washer (#C) onto that same bolt (#A). 2. Align the base (#4) to the holes along the end of the legs, then insert the bolts.
