VERSION
# 19-10-11
1 / 8
MODEL #
CM3716PC-2PK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - Persons
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM3716PC-2PK
Summary of Contents for Furniture of America CM3716PC-2PK
- Page 1 MODEL # CM3716PC-2PK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - Persons Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 8...
- Page 5 CHAIR CM3716PC-2PK #1 1pc x2 #2 1pc x2 #3 2pcs x2 Seat Chair Back Front Leg (L/R) #4 x 2pcs x2 #5 x 1pc x2 Front stretcher Side stretcher L/R #C 2pcs x2 #B 4pcs x2 #A 4pcs x2 #D 10pcs x2 Bolt Ø1/4"...
-
Page 6: Exploded View
Exploded View 6 / 8... - Page 7 ASSEMBLY INSTRUCTIONS Align seat (#2) to chair back (#1), then secure holes by using bolts (#C) with washers (#D,E). Part #1 x1pc Part #2 x1pc Hardware #C x2pcs Hardware #D x2pcs Hardware #E x2pcs Secure corners holes of seat (#2) to chair back (#1) by using bolts (#A) with washers (#D,E).
- Page 8 ASSEMBLY INSTRUCTIONS Align stretchers (#4R/L,5) to legs (#3R/L) and chair back, then secure legs (#3R/L) to seat (#2) by using bolts (#B) with washers (#D,E). Part #3 x2pcs Part #4 x2pcs Part #5 x1pc Hardware #B x4pcs Hardware #D x4pcs Hardware #E x4pcs Secure stretchers to legs by using...
