MODEL #
CM3752PT-5PK
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America Ann CM3752PT-5PK
Summary of Contents for Furniture of America Ann CM3752PT-5PK
- Page 1 MODEL # CM3752PT-5PK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 5PC. COUNTER HT. TABLE SET-TABLE CM3752PT-5PK Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. PARTS # 2 4pcs # 3 1pc # 1 1pc Table Top Table leg Table Shelf HARDWARE # A 12pcs # B 12pcs...
- Page 6 1)Prepare 8 bolts assembly by Spring Washer (#B),than flat washer (#C) onto bolts(#A).Align legs (#2)to the holes of the table top (#1).secure by ueing bolts (#A) ,but do not fully tighten. adjust leveler P art #1 X 1pc Part #2 X 4pcs Hardware #A X 8pcs #B X 8pcs Hardware...
- Page 7 5PC. COUNTER HT. TABLE SET-CHAIR CM3752PT-5PK Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. PARTS #2 1pc x4 #1 1pc x4 #3 2pcs x4 #4 2pcs x4 #5 1pc x4 Side stretcher L/R Chair back Seat...
- Page 8 Prepare 2 bolts assembly by Spring Washer (#D),than flat washer (#E) onto bolts(#C).Align seat frame(#3) to the chair back(#1).then secure by ueing bolts (#C) Do not fully tighten bolts(#C). P art #1 X 1pc P art #3 X 1pc # C X 2pcs Hardware #D X 2pcs Hardware...
- Page 9 Prepare 4 bolts assembly by Spring Washer (#D),than flat washer (#E) onto bolts(#B).Align front legs(#4) to the holes of the chair frame(#3).Secure by using bolts(#B) P art #4 X 2pcs # B X 4pcs Hardware # D X 4pcs Hardware #E X 4pcs Hardware P art #4 X 2pcs...
