Furniture of America CM3710PC-2PK Assembly Instructions Manual

CM3710PC-2PK

ASSEMBLY RATING

Tools Required for Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

Allen Wrench

(Included)

assembling a specific product (with 1 being

easy and 5 being difficult). For some

products, two persons are recommended.

Phillips Screwdriver

(Not Included)

DIFFICULT

EASY

Page 1 of 6

Rev.14-08-18

Table of Contents

Do you have a question about the CM3710PC-2PK and is the answer not in the manual?

Page 1 Assembly Instructions CM3710PC-2PK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
Page 3 Page 3 of 6...
Page 4 Before you begin, please read Page 3 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc x 2 #A x 10 pcs x 2 Backrest w/Legs Flat Washer #B x 10 pcs x 2...
Page 5 #A x 2 pcs #B x 2 pcs Turn right (clockwise) to tighten #D x 2 pcs Place the backrest with legs (#1) on a protected surface. Align the seat (#2) with the pre-drilled holes of the backrest with legs (#1). Prepare 2 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#D)
Page 6 #A x 4 pcs Insert the front leg support (#7) #B x 4 pcs between the right front leg (#3) #E x 4 pcs and the left front leg (#4). II. Insert the right leg support (#5) Note: Right and left are determined by facing the front of and the left leg support (#6) into the chair in the upright position.
