- Page 1 WL-10 Mini ITX Motherboard...
- Page 2 Copyright © 2022 Shenzhen Maxtang Computer Co., Ltd. All rights reserved. No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of Shenzhen Maxtang Computer Co., Ltd (hereinafter referred to as “Maxtang”).
- Page 3 Shenzhen Maxtang Computer Co., Ltd WL-10 Mini ITX Motherboard User Manual (Version 1.3) Version: Description Issue Date: V1.0 Initial version. 2019/10/15 V1.2 Added E_DIS jumper cap switch LVDS/EDP 2020/08/31 V1.3 LAN 1 changed to Intel i219 2022/01/21...
-
Page 4: Table Of Contents
Shenzhen Maxtang Computer Co., Ltd Contents Chapter 1 Product Introduction ...................... 3 1.1 Brief Introduction ........................3 1.2 Parameters ..........................3 1.3 Connector Diagram ........................4 Chapter 2 Hardware ........................6 2.1 Jumper Setting .......................... 6 2.2 Memory Slots ..........................6 2.3 Display interface ........................ -
Page 5: Chapter 1 Product Introduction
Shenzhen Maxtang Computer Co., Ltd Chapter 1 Product Introduction 1.1 Brief Introduction The WL10 is based on the Intel Whiskey Lake-U platform. 1.2 Parameters Whiskey Lake-U platform: ⚫ i7-8565U--quad core, 1.8 GHz, TDP 15W, supporting Turbo Boost Technology and EIST ⚫... -
Page 6: Connector Diagram
Shenzhen Maxtang Computer Co., Ltd 1.3 Connector Diagram 1*USB3.0 HDMI DC_IN AUDIO LAN2 USB3.0 LAN1 1*USB2.0 PWR3 FP-AUDIO EDP/LVDS_ADJ JAUD SATA2 M.2_SSD/3G/4G BKADJ_C EDP/LVDS PCIEX4 M.2_WIFI E_DIS PWSATA1 PWSATA2 SATA1 COM6 COM1 MEMORY COM2_P SYS_FAN COM4_P CPU_FAN JPOWER1 COM25 PS2_H... - Page 7 Shenzhen Maxtang Computer Co., Ltd MEMORY...
-
Page 8: Chapter 2 Hardware
Shenzhen Maxtang Computer Co., Ltd Chapter 2 Hardware 2.1 Jumper Setting Please configure the jumpers according to your requirements before installing the hardware. How to identify the first header of jumpers and pins: Observe the mark beside the jumper or pins and find the header marked by “1”... -
Page 9: Edp (Screen Printing: Lvds, Lvds_Adj, J3, E_Dis)
Shenzhen Maxtang Computer Co., Ltd B_DATA3_DN B_DATA3_DP Display backlight brightness adjustment pin (screen printing: EDP/LVDS_ADJ) Signal LCD_BKL_ADJ LCD_BKL_ON LVDS display backlight two-way adjustment jumper (screen printing: BKLADJ_C) Settings Function Close Backlight Control Flip Close Backlight Control Forward Display power supply jumper (screen printing: J3) - Page 10 Shenzhen Maxtang Computer Co., Ltd Signal Signal EDP_DATA0_P EDP_DATA0_N EDP_DATA1_P EDP_DATA1_N eDP Display backlight brightness adjustment pin (screen printing: EDP/LVDS_ADJ) Signal LCD_BKL_ADJ LCD_BKL_ON eDP display backlight two-way adjustment jumper (screen printing: BKLADJ_C) Settings Function Close Backlight control flip Close Backlight control forward...
-
Page 11: Hdmi Pin (Screen Printing: Jhdmi)
Shenzhen Maxtang Computer Co., Ltd 2.4 HDMI pin (screen printing: JHDMI) The board is equipped with pin HDMI interface as backup option. The interface can work with the standard HDMI interface at the same time. JHDMI (screen printing: JHDMI) Signal... -
Page 12: Lan
Shenzhen Maxtang Computer Co., Ltd USB DATA- USB DATA- USB DATA+ USB DATA+ (NC) 2.8 LAN High-performance Gigabyte Ethernet controller, features 1x intel i219 and 1x intel i211, with 2 x RJ45 interfaces. Supporting Magic packet wake up. LAN1 supports PXE network boot. -
Page 13: Com (Screen Printing: Com1, Com25, Com6, Jcom2_P, Jcom4_P)
Shenzhen Maxtang Computer Co., Ltd SPDIF (screen printing: SPDIF) Signal SPDIF_Out 2.10 COM (screen printing: COM1, COM25, COM6, JCOM2_P, JCOM4_P) It is equipped with 6 COM (2.0mm spacing of built-in pins). COM1 slots are defined by industrial control; COM1 to COM5 are RS232 mode, and COM6 is RS485 mode. COM2_P and COM4_P provide optional 5V or 12V voltage for COM2 and COM4. -
Page 14: Lpt (Screen Printing: Lpt)
Shenzhen Maxtang Computer Co., Ltd DTR# DSR# RTS# CTS# DCD# DTR# DSR# RTS# CTS# COM6 (screen printing: COM6) Signal Signal DATA- DATA+ (NC) COM2_P, COM4_P (screen printing: COM2_P、COM4_P) Interfac Settings Function Close Close Close 2.11 LPT (screen printing: LPT) On-board 1 set of 2X13 pin LPT interface. The adapter cable is needed to transfer the LPT to the standard parallel interface for use. -
Page 15: Gpio Pin (Screen Printing: Gpio)
Shenzhen Maxtang Computer Co., Ltd LPT_ PPD0 ERROR LPT_ PPD1 INIT LPT_ PPD2 SLIN LPT_ PPD3 LPT_ PPD4 LPT_ PPD5 LPT_ PPD6 LPT_ PPD7 BUSY SLCT (NC) 2.12 GPIO pin (screen printing: GPIO) The board is equipped with a set of 2 x 5pin as JGPIO pin (2.0mm spacing), supporting 8 programmable I/O lanes in total. -
Page 16: Board Power Supply (Screen Printing: Pwr1, Pwr3)
Shenzhen Maxtang Computer Co., Ltd KB_DATA KB_CLK MS_ DATA MS_CLK 2.14 Board power supply (screen printing: PWR1, PWR3) It supports 12V DC-in power adapter or ATX 12V supplementary power (2 x 2pin). PWR1: 12V DC-in power socket PWR3: ATX12V supplementary power supply socket (2x2PIN) 2.15 Switch panel pin (screen printing: JPOWER1) -
Page 17: Hardware Auto Start (Screen Printing: Jat)
Shenzhen Maxtang Computer Co., Ltd 2.16 Hardware auto start (screen printing: JAT) JAT (screen printing: JAT) Settings Close Hardware auto start Please note that this jumper function is similar to the "Restore AC power loss" function in BIOS. When the latter is set to Power on, the device will also start automatically after power is connected.
