5. Do not affix the unit to wall or ceilings that have inadequate strength to permanently hold the unit during use. It is the owner’s and installer’s responsibility to confirm the wall to which the unit attaches is sufficient to permanently hold the weight and stress loads of the unit at all times. Draper, Inc., is not responsible for improper installation, application, testing or workmanship related to the product at place of installation.
page 4 of 32 Foundation for LED Panels ™ Section 2 - Components HORIZONTAL RAILS WALL MOUNTING BRACKETS VERTICAL RAIL VERTICAL RAILS HORIZONTAL RAIL FASTENERS SCREW CONNECTORS M6 -1x10mm SLIDE-IN NUT M6-1.0 6 Panels 7 Panels SPLIT LOCK High High WASHER .25"...
Page 5
page 5 of 32 Foundation for LED Panels ™ TOP LEFT TRIM SECTION TOP RIGHT TRIM SECTION Section 2 - Trim Frame Components (continued) TOP CENTER TRIM SECTION RIGHT TRIM TOP TRIM TION SECTION TOP LEFT TRIM TOP RIGHT TRIM ATTACHMENT ATTACHMENT BRACKET...
Page 6
page 6 of 32 Foundation for LED Panels ™ Section 3 - Determining Horizontal Mounting Location Section 3.1 - For LED arrays up to 6 panels high - 2 Horizontal Rails The Foundation Wall Brackets must be securely anchored to the wall. If mounting to drywall/gypsum board wall, all mounting hardware must be (by others) anchored to a vertical stud.
Page 7
page 7 of 32 Foundation for LED Panels ™ STANDARD ARRAY MOUNTING DIMENSIONS DIM A FINAL VIEWING AREA Array HEIGHT WIDTH Vertical distance from Bottom Left of to Top Size Rail Mounting Hardware 95 3 / 4 " 53" 53 7/ 8 " (1345mm) (1368mm) (2432mm)
Page 8
page 8 of 32 Foundation for LED Panels ™ Section 3.2 - For LED arrays 7 panels or higher - 3 Horizontal Rails The Foundation Wall Brackets must be securely anchored to the wall. If mounting to drywall/gypsum board wall, all mounting hardware must be (by others) anchored to a vertical stud.
Page 9
page 9 of 32 Foundation for LED Panels ™ STANDARD ARRAY MOUNTING DIMENSIONS DIM A DIM B FINAL VIEWING AREA Array HEIGHT WIDTH Vertical distance from Bottom Left of Array Vertical distance from Bottom Left of Array Size to Middle Rail Mounting Hardware to Top Rail Mounting Hardware 53"...
Page 10
page 10 of 32 Foundation for LED Panels ™ Section 3.2 - Marking Vertical Mounting locations Section 3.2.2 - CONCRETE, BLOCK OR BRICK INSTALLATION Section 3.2.1 - WOOD/METAL STUD INSTALLATION 1. Locate the wall studs and mark their location at the intersection of the 1.
Page 11
page 11 of 32 Foundation for LED Panels ™ L RAILS Section 4 - Assembling Horizontal Rails MOUNTING BRACKET The horizontal rails must be assembled prior to being secured to the wall. DETAIL HORIZONTAL RAIL A complete Horizontal Rail consists of Wall Mounting Brackets engaged in both SECTION PROFILE SLIDES INTO TOP and BOTTOM Channels of extruded rail sections...
Page 12
page 12 of 32 Foundation for LED Panels ™ Section 5 - Hanging Horizontal Rails Section 5.1 - For LED arrays up to 6 panels high - 2 Horizontal Rails 1. Using the top keyhole slots of the two outer wall mounting brackets, hang the bottom horizontal rail on the pre-installed mounting hardware (see Section 3, Step 5) W A L L...
Page 13
page 13 of 32 Foundation for LED Panels ™ Section 5.2 - For LED arrays 7 panels or higher - 3 Horizontal Rails 1. Using the top keyhole slots of the outer wall mounting brackets, hang the BOTTOM W A L L horizontal rail on the pre-installed mounting hardware (see Section, 3 Step 5) 2.
page 14 of 32 Foundation for LED Panels ™ Section 6 - Adjusting and Aligning Horizontal Rails 1. Push the wall brackets against the wall where they will be mounted. Depending on the flatness of the wall some brackets may not touch the wall (see Fig.
Page 15
page 15 of 32 Foundation for LED Panels ™ Section 7 - Securing Inner Wall Brackets 1. Secure each bracket to the wall with the appropriate mounting hardware. 2. Check the distance from the laser line at each wall bracket to ensure nothing moved while fastening to the wall. Adjust if necessary. 3.
Page 16
page 16 of 32 Foundation for LED Panels ™ Section 8.2 - Vertical Rail Assembly - For LED arrays 7 panels or higher - 3 Horizontal Rails WORK GLOVES RECOMMENDED Section 8.2.1 - Lower Section of Vertical Rail Assembly 1. Insert Vertical Connector into TOP of the Lower Vertical Rail section and secure with provided hardware (3mm Hex Wrench) VERTICAL Front...
Page 17
page 17 of 32 Foundation for LED Panels ™ Section 9 - Inserting Front Rail Connector and Vertical Rail Fasteners Section 9.1 - For LED arrays up to 6 panels high - 2 Horizontal Rails 1. Insert horizontal rail connector and vertical rail fasteners into the top and bottom horizontal rails. 5 Vertical Rails 4 4 5 4 4 5...
Page 18
page 18 of 32 Foundation for LED Panels ™ Section 9.2 - For LED arrays 7 panels or higher - 3 Horizontal Rails 1. Insert horizontal rail connector and vertical rail fasteners into the top, middle and bottom horizontal rails. 9 Vertical Rails Splice Splice...
Page 19
page 19 of 32 Foundation for LED Panels ™ Section 10 - Attaching Vertical Rails Section 10.1 - For LED arrays up to 6 panels high - 2 Horizontal Rails WORK GLOVES RECOMMENDED 1. Hang the Vertical Rails on the top horizontal rail and space evenly. 2.
Page 20
page 20 of 32 Foundation for LED Panels ™ Section 10.2 - For LED arrays 7 panels or higher - 3 Horizontal Rails Section 10.2.1 - Attaching Bottom Vertical Sections 1. Lift each Vertical Rail and position it on the middle rail. 2.
Page 21
page 21 of 32 Foundation for LED Panels ™ Section 11 - Adjusting Verticals Section 11.1 - Y - Axis Adjustment WORK GLOVES RECOMMENDED Section 11.1.1 - For LED arrays up to 6 panels high - 2 Horizontal Rails 1. Locate the highest Vertical Rail and shine a laser level line across utilizing the laser level notch. 2.
Page 22
page 22 of 32 Foundation for LED Panels ™ Section 11.2 - X - Axis Adjustment (Squaring Verticals with provided Alignment Tool) Section 11.2.1 - For LED arrays up to 6 panels high - 2 Horizontal Rails 1. Shine a laser line at the left edge of the Adjust Vertical structure and check that the first Vertical Rail Rails Until...
Page 23
page 23 of 32 Foundation for LED Panels ™ Section 11.2.2 - For LED arrays 7 panels or higher - 3 Horizontal Rails 1. Shine a laser line at the left edge of the structure and check that the first Vertical Rail is square with the floor. To adjust, loosen the fasteners installed in Section 10, Step 3 and slide the Vertical Rail along the Horizontal Rail until.
Page 24
page 24 of 32 Foundation for LED Panels ™ Section 11.3 - Z - Axis Adjustment Fig. 11.3-1 1. Using a 3mm hex wrench, adjust each Wall Adjuster Bracket until it contacts the wall. 3mm Hex Wrench 2. Use the clearance hole in the vertical rail to allow for a socket to drive a lag screw into the wall.
Page 25
page 25 of 32 Foundation for LED Panels ™ WALL ADJUSTER BRACKET Adjust Wall Adjustment Brackets ASSEMBLY Until All Vertical Rails are flush. Differential Bubble Level recommended. Screw 3mm Hex Wrench...
Page 26
EFT TRIM SECTION TOP RIGHT TRIM SECTION page 26 of 32 Foundation for LED Panels ™ TOP CENTER TRIM SECTION Section 12 - Attaching Trim Brackets RIGHT TOP TRIM SECTION Section 12.1 - Installing Center Top Trim Brackets TOP LEFT TRIM TOP RIGHT TRIM ATTACHMENT ATTACHMENT...
Page 27
TOP RIGHT TRIM SECTION TOP LEFT TRIM SECTION page 27 of 32 Foundation for LED Panels ™ RIGHT LEFT TOP TRIM TOP TRIM Section 12.2 - Installing Outer Top Trim Brackets SECTION SECTION TOP RIGHT TRIM TOP LEFT TRIM ATTACHMENT ATTACHMENT BRACKET BRACKET...
Page 28
page 28 of 32 Foundation for LED Panels ™ Section 13 - Attaching LED Panels LED Cabinets Section 13.1 - Attaching Spring-Loaded Fasteners 1. Replace the mounting bolts in the LED cabinet with the provided (pre-installed by LED manufacturer) Spring Loaded mounting studs. M10 Spring Loaded Mounting Stud Section 13.2 - Attaching LED Panels...
page 29 of 32 Foundation for LED Panels ™ 2. Attach the next LED cabinet direct to the right of the first. Continue until the first row is complete. 3. Working from left to right, attach the row of LED cabinets. 4.
Page 30
page 30 of 32 Foundation for LED Panels ™ Section 14 - Attaching Foam Tape to Completed LED Array 1. Apply foam tape around the outer edges of the display before installing the trim. Foam tape will cover the previously installed Sony clips. ATTACH FOAM TAPE TO COMPLETE LED ARRAY...
Section 15 - Attaching Trim to Trim Brackets TOP LEFT TRIM SECTION TOP RIGHT TOP CORNERS: Top Trim First, Then SIDE TRIM TOP CENTER TRIM SECTION LEFT TOP TRIM SECTION TOP LEFT TRIM TOP R ATTACHMENT ATTA BRACKET TOP CENTER TRIM C002.1735SA ATTACHMENT C002...
