FS
1 Mode Hand Shower Unit
Installation Guide
Model Numbers
☐
FS
Options/Modifications
☐
CG
-1.5
1.5 gpm (5.7 L/min) flow restrictor
☐
-2.0
2.0 gpm (7.6 L/min) flow restrictor
☐
-STN
Satin Nickel finish
Note: Append appropriate -suffix to model number.
Compliance
- ASME A112.18.1/CSA B125.1
Dimensions
1 Mode Hand Shower Unit
A
FLOOR
FLOOR
Feature Highlights
•
1 mode hand shower
•
3" diameter hand shower head
•
Dual checks for backflow protection
•
Cradle for hand shower mounting with swivel
•
60" flexible metal hose
•
Standard 2.5 gpm (9.5 L/min) flow restrictor
•
Shall be metal and nonmetallic construction, plated in
standard polished chrome finish
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
B B
C C
Note: Dimensions subject to change without notice.
Measurements
A
Ø 2-1/2", 64 mm
B
1-1/2", 38 mm
Male 1/2" IPS fitting must
C
protrude 3/8" (10 mm)
from finished wall
