TROUBLESHOOTING
The following contains general troubleshooting problems and solutions for Merit flat saws, please
refer to the Owner's Manual that is specific to your saw. If you do not have a manual or do not know the
model of your saw, please check the ID Plate located in the lower rear control panel near the battery.
For additional questions, or to request a copy of the Owner's Manual,
please email: Service@icsdiamondtools.com.
Problem Possibilities
Pump pressure set too low
Low hydraulic oil/leaking oil
Bad lift pump
Loss of 12v power supply
Hydraulic oil leak or low oil level
Saw will not
raise, or
rises slowly out
of the cut
Standard (Mechanical lever)
models- valve is partially
open when lever is in the
closed position
Button Style models
(electric version) - dump valve
bypass is stuck open
Faulty check-valve in the pump
manifold
CUSTOMER SUPPORT: 800.321.1240 EMAIL: orders@icsdiamondtools.com
Rev 12.17.19
Solution (see "How to")
Increase pump pressure
Replace lift pump
Call service for support
Check connections to the solenoid
Check ground connection to the pump
Check connections at the battery posts
Check solenoid
Check battery charge
Check fittings and hoses for leaks, and
check oil level in reservoir
Make sure red lever (under control
panel) is in the closed position
Review Raise/Lower instruction sheet,
call service for assistance
Replace valve
Remove check-valve and inspect for
debris that may cause stuck valve or
faulty spring
How to
Pump pressure can be increased or decreased
by adjusting the pressure relief setting located
on the pump manifold. Make small adjustments
and recheck - Add blade guard(s) to the front of
the saw for extra load weight.
Make sure there are no cracks or breaks in the
copper solenoid bracket, and battery posts/
conections are tight and free of debris.
Test solenoid using a multimeter or
other device, check the battery for
proper voltage.
Inspect the fittings, connections and along the
hose routing for oil leaks and seepage.
Note: always support the weight of the saw
when working with a raised hydraulic system
(under pressure). Reservior contains 1 qt of ATF.
Remove the rear panel to access the red
lever. Loosen the 5/16 bolt and nut holding
the red lever to the main body assembly. Push
red lever forward until the valve has reseated.
Tighten bolt and nut on red lever to secure to
main body.
Lower the saw completely to relieve all pressure
in the valve and system. Locate the valve from
the manifold and replace. See technical sheets.
Lower the saw completely to relieve all pressure
in the valve and system. Remove the raise
control valve and fitting to expose the
check-valve inside of the pump manifold. Using
a 3/8 allen wrench, turn clockwise and remove
set screw. Visually inspect for debris.
Compressed air may be used to clear.
See technical sheets.
