2.3.2

ImageChecker CAD with DICOM 6000 Data Flow

Typically, diagnostic review workstations and PACS devices support the Mammography
CAD SR results format. If the review workstation or PACS does not support
Mammography CAD SR, but does support DICOM 6000 overlays, a supplementary
interface solution can be installed. For more information about the Hologic DICOM 6000
interface option, contact your Hologic Account Manager.
Image Acquisition System(s)
1, 2, 3, 4: The FFDM device sends For Processing images to the Cenova server, and For
Presentation images to the diagnostic review workstation(s), PACS, and DICOM 6000
Interface.
Cenova Server
5: The Cenova server sends CAD results in DICOM Mammography CAD SR format to
the DICOM 6000 Interface. No images need be forwarded.
DICOM 6000 Interface
6: The DICOM 6000 Interface sends the images with DICOM 6000 CAD results overlays
to the diagnostic workstation for review and to the PACS for storage.
Note
The DICOM 6000 Interface may reside on a Cenova server.
Diagnostic Review Workstation(s) and PACS
3, 6: The review workstation receives the For Presentation images and the For
Presentation images with DICOM 6000 CAD results overlays, which then can be
reviewed by the radiologist.
7: If results are stored on a PACS, then they can be retrieved and sent to the review
workstation at any time.
