Harrod FBL-580 Instructions

FBL-580/583/586/588/581/584/587/589/592/593
Code:
780/783/786/788/781/784/787/789/792/793
Product:
3G Folding Projection Goal
8
IMPORTANT Please read through the
instructions before assembling your goals.
Socket Location: Behind Fence
Item number:
Product Size Projection
FBL-580 4.88x1.22m 2.3 to 3.5m 1 FEP318 2 FEP299 4 FBL-291 2 FEQ331 1 FEP311 2 FEP320 2 FEP697 2 FEP698 1 FEP699 1 FPK313
FBL-583 4.88x1.22m 3.5 to 5m
FBL-586 4.88x1.83m 2.3 to 3.5m 1 FEP318 2 FEP300 4 FBL-291 2 FEQ331 1 FEP311 2 FEP320 2 FEP694 2 FEP695 1 FEP696 1 FPK313
FBL-588 4.88x1.83m 3.5 to 5m
FBL-581 3.66x1.22m 2.3 to 3.5m 1 FEP317 2 FEP299 4 FBL-291 2 FEQ331 1 FEP311 2 FEP320 2 FEP697 2 FEP698 1 FEP699 1 FPK313
FBL-584 3.66x1.22m 3.5 to 5m
FBL-587 3.66x1.83m 2.3 to 3.5m 1 FEP317 2 FEP300 4 FBL-291 2 FEQ331 1 FEP311 2 FEP320 2 FEP694 2 FEP695 1 FEP696 1 FPK313
FBL-589 3.66x1.83m 3.5 to 5m
FBL-592 4.88x2.13 2.3 to 3.5m 1 FEP318 2 FEQ117 4 FBL-291 2 FEQ331 1 FEP311 2 FEP320 2 FEP694 2 FEP695 1 FEQ575 1 FPK313
FBL-593 4.88x2.13 3.5 to 5m
Socket Location: In Front of Fence
Item number:
Product Size Projection
FBL-780 4.88x1.22m 2.5 to 3.7m 1 FEP318 2 FEP299 4 FBL-291 2 FEQ331 1 FEP141 2 FEP320 2 FEP697 2 FEP698 1 FEP699 1 FPK313
FBL-783 4.88x1.22m 3.7 to 5.2m 1 FEP318 2 FEP299 4 FBL-291 2 FEQ331 1 FEP141 2 FEP316 2 FEP708 2 FEP709 1 FEP699 1 FPK313
FBL-786 4.88x1.83m 2.5 to 3.7m 1 FEP318 2 FEP300 4 FBL-291 2 FEQ331 1 FEP141 2 FEP320 2 FEP694 2 FEP695 1 FEP696 1 FPK313
FBL-788 4.88x1.83m 3.7 to 5.2m 1 FEP318 2 FEP300 4 FBL-291 2 FEQ331 1 FEP141 2 FEP316 2 FEP706 2 FEP707 1 FEP696 1 FPK313
FBL-781 3.66x1.22m 2.5 to 3.7m 1 FEP317 2 FEP299 4 FBL-291 2 FEQ331 1 FEP141 2 FEP320 2 FEP697 2 FEP698 1 FEP699 1 FPK313
FBL-784 3.66x1.22m 3.7 to 5.2m 1 FEP317 2 FEP299 4 FBL-291 2 FEQ331 1 FEP141 2 FEP316 2 FEP708 2 FEP709 1 FEP699 1 FPK313
FBL-787 3.66x1.83m 2.5 to 3.7m 1 FEP317 2 FEP300 4 FBL-291 2 FEQ331 1 FEP141 2 FEP320 2 FEP694 2 FEP695 1 FEP696 1 FPK313
FBL-789 3.66x1.83m 3.7 to 5.2m 1 FEP317 2 FEP300 4 FBL-291 2 FEQ331 1 FEP141 2 FEP316 2 FEP706 2 FEP707 1 FEP696 1 FPK313
FBL-792 4.88x2.13m 2.5 to 3.7m 1 FEP318 2 FEQ117 4 FBL-291 2 FEQ331 1 FEP141 2 FEP320 2 FEP694 2 FEP695 1 FEQ575 1 FPK313
FBL-793 4.88x2.13m 3.7 to 5.2m 1 FEP318 2 FEQ117 4 FBL-291 2 FEQ331 1 FEP141 2 FEP316 2 FEP706 2 FEP707 1 FEQ575 1 FPK313
View of Product
1
Pack Contents
1 2 3
Crossbar Upright Socket
1 FEP318 2 FEP299 4 FBL-291 2 FEQ331 1 FEP311 2 FEP316 2 FEP708 2 FEP709 1 FEP699 1 FPK313
1 FEP318 2 FEP300 4 FBL-291 2 FEQ331 1 FEP311 2 FEP316 2 FEP706 2 FEP707 1 FEP696 1 FPK313
1 FEP317 2 FEP299 4 FBL-291 2 FEQ331 1 FEP311 2 FEP316 2 FEP708 2 FEP709 1 FEP699 1 FPK313
1 FEP317 2 FEP300 4 FBL-291 2 FEQ331 1 FEP311 2 FEP316 2 FEP706 2 FEP707 1 FEP696 1 FPK313
1 FEP318 2 FEQ117 4 FBL-291 2 FEQ331 1 FEP311 2 FEP316 2 FEP706 2 FEP707 1 FEQ575 1 FPK313
1 2 3
Crossbar Upright Socket
Sockets behind the
9
fence/kickboard
4
2
4 5
Thro
Support Fence Internal
Post Arm Adjuster
4 5
Support
Support Post Internal
Post Hinge Adjuster
Sockets in front of the
fence/kickboard
4
5
6
AT LEAST 3 PEOPLE ARE REQUIRED
TO ASSEMBLE THIS PRODUCT.
6 7 8
L/H R/H
Bottom Bottom
Sidebar Sidebar
6 7 8
L/H R/H
Bottom Bottom
Sidebar Sidebar
INS597
Revision 8
06/04/2018
© Harrod UK Limited
5
6
9 10
Folding
Goal Net
Support Fittings
9 10
Folding
Goal Net
Support Fittings
