ASSEMBLY INSTRUCTIONS
FBL-545-4G, FBL-635-4G, FBL-637-4G, FBL-644-4G, FBL-645-4G,
FBL-646-4G, FBL-652-4G, FBL-654-4G, FBL-655-4G, FBL-656-4G, FBL-658-4G
4G Original Weighted Roller Goal
2 people are recommended for this assembly
60
Estimated 1 hour assembly time.
mins
IMPORTANT: Goal shown is senior size 7.32x2.44m. (Some goals
i
will be supplied with handle, not wheels)
IMPORTANT: Please read these assembly instructions carefully
i
before starting to assemble your goal.
INS610
Revision 1
08/10/2020
