ATI Technologies A15/82 O & M Manual

Fluoride monitor with auto-calibration
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Fluoride Monitor
Home Office
Analytical Technology, Inc.
6 Iron Bridge Drive
Collegeville, PA 19426
Ph: (800) 959-0299
(610) 917-0991
Fax: (610) 917-0992
Email: sales@analyticaltechnology.com
Model A15/82
European Office
ATI (UK) Limited
Unit 1 & 2 Gatehead Business Park
Delph New Road, Delph
Saddleworth OL3 5DE
Ph: 0800-018-4020
+ 44 (0) 1457-873-318
Fax: + 44 (0) 1457-874-468
Email: sales@atiuk.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A15/82 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ATI Technologies A15/82

Summary of Contents for ATI Technologies A15/82

  • Page 1 Model A15/82 Fluoride Monitor Home Office European Office Analytical Technology, Inc. ATI (UK) Limited 6 Iron Bridge Drive Unit 1 & 2 Gatehead Business Park Collegeville, PA 19426 Delph New Road, Delph Saddleworth OL3 5DE Ph: (800) 959-0299 Ph: 0800-018-4020...
  • Page 2 PRODUCT WARRANTY Analytical Technology, Inc. (Manufacturer) warrants to the Customer that if any part(s) of the Manufacturer's products proves to be defective in materials or workmanship within the earlier of 18 months of the date of shipment or 12 months of the date of start-up, such defective parts will be repaired or replaced free of charge.

  • Page 3: Table Of Contents

    CONTROL & ALARM OUTPUTS ..........................27 CONTROL RELAYS ..............................27 ALARM RELAY ................................28 MAINTENANCE ................................29 BUFFER REPLENISHMENT ............................29 SENSOR MAINTENANCE ............................29 PUMP MAINTNANCE ..............................29 SPARE PARTS - MODEL A15/82 ..........................31 O&M Manual Rev-G (6/10)
  • Page 4 Model A15/82 Fluoride Monitor with Auto-Calibration TABLE OF FIGURES Figure 1 - Fluoride Monitoring System ..................6 Figure 2 - Panel Mount Dim & Installation .................. 8 Figure 3 - NEMA 4X Wall Mount Dim..................9 Figure 4 - Fluroide Montior Chem Module ................10 Figure 5 - Sample Inlet and Drain Chamber ................

  • Page 5: Unpacking

    Compare the contents of the shipping container with the packing list. The items listed above are the standard components that are included with every standard A15/82 monitor. Any other items will be listed separately on the packing list. Check the contents of the shipping container carefully to insure that nothing is overlooked.

  • Page 6: Introduction

    0-100 or 0-1000 PPM by proper field calibration. The analog output signal may be spanned for smaller ranges within the overall operating ranges if desired. A15/82 monitors are designed to operate on sample temperatures from 0° to 50 °C. Because water is flowing through the chemistry module at a low rate, this unit cannot be exposed to temperatures below 0°...

  • Page 7: Figure 1 - Fluoride Monitoring System

    Model A15/82 Fluoride Monitor with Auto-Calibration Figure 1 - Fluoride Monitoring System O&M Manual Rev-G (6/10)

  • Page 8: Specifications

    Model A15/82 Fluoride Monitor with Auto-Calibration SPECIFICATIONS ELECTRONIC MONITOR Range: 0-1.00 PPM Minimum, 0-1000 PPM Maximum Accuracy: ± 5% of Span Repeatability: ± 2% of Span Drift: < 0.1 PPM per month Display: 16 character alphanumeric backlit LCD Calibration: Automatic calibration at operator programmable interval.

  • Page 9: Installation

    Model A15/82 Fluoride Monitor with Auto-Calibration INSTALLATION The main installation requirements for the ATI Fluoride Monitor are mechanical installation of the monitor chemistry module, and sample inlet overflow chamber, connection of power to both monitor and chemistry module, and connection of sample and drain piping to the sample overflow chamber supplied with the system.

  • Page 10: Figure 3 - Nema 4X Wall Mount Dim

    Model A15/82 Fluoride Monitor with Auto-Calibration The optional NEMA 4X wall mount enclosure is a molded plastic unit that bolts directly to a wall or other flat surface. The enclosure is supplied with special mounting bracket for convenience in mounting the enclosure.

  • Page 11: Figure 4 - Fluroide Montior Chem Module

    Model A15/82 Fluoride Monitor with Auto-Calibration The chemistry module contains the components required to condition the sample and measure the fluoride concentration under stable conditions. This package includes sample and buffer pumps, the fluoride ISE, and a sensor flow chamber.

  • Page 12: Sample Inlet Overflow

    Model A15/82 Fluoride Monitor with Auto-Calibration SAMPLE INLET OVERFLOW The water sample supplied to the monitor is connected to a special overflow chamber. This is done to insure that the sample flowrate to the monitor is sufficient to insure that fresh sample is always available at the sample pickup point.

  • Page 13: Buffer And Calibration Standard Bottle Holders

    Model A15/82 Fluoride Monitor with Auto-Calibration BUFFER AND CALIBRATION STANDARD BOTTLE HOLDERS Two bottle mounting brackets are supplied so that the buffer and fluoride standard solution can be located conveniently below the chemistry module. The brackets are designed for wall mounting, and will hold one gallon plastic containers.

  • Page 14: Reagent And Fluoride Standard Pickup Tubing Connection

    Model A15/82 Fluoride Monitor with Auto-Calibration REAGENT AND FLUORIDE STANDARD PICKUP TUBING CONNECTION A special rubber stopper with a ceramic support tube is supplied for the buffer and fluoride standard bottles. If necessary, adjust the ceramic tube so that it does not hit the bottom of the solution bottles. A length of pickup tubing is supplied for each of these pickup assemblies with a small filter attached to one end of the buffer tubing.

  • Page 15: Electrical Connections

    ELECTRICAL CONNECTIONS Wiring connections to the A15/82 are made to the back of the monitor. The terminal blocks on the back of the monitor are pluggable terminals for ease of wiring. Power and alarm relay connections are made to the lower terminal block while sensor and analog output connections are made to the upper block.

  • Page 16: Figure 9 - Figure 9 Chemistry Module Power Connection

    Model A15/82 Fluoride Monitor with Auto-Calibration The fluoride chemistry module requires AC power for operation of internal sample and buffer pumps. An AC power cord is supplied. Permanent wiring should be made to the terminals shown in Figure 9 below. The sensor wire is an unbroken coaxial wire running directly into the monitor.

  • Page 17: Start-Up

    Model A15/82 Fluoride Monitor with Auto-Calibration START-UP Prior to operation, recheck electrical connections to be sure everything is in accordance with Figure 8 and Figure 9. If everything is in order, power may be applied. When power is turned on, the display will come up with a program and version number, which will remain on the display for a few seconds.

  • Page 18: Front Panel Lock

    Model A15/82 Fluoride Monitor with Auto-Calibration FRONT PANEL LOCK The key switches on the front panel of the monitor can be used for both changing the display and for calibrations and setpoint adjustments. When the monitor is shipped from ATI, all functions are accessible.

  • Page 19: Configuration

    Model A15/82 Fluoride Monitor with Auto-Calibration CONFIGURATION The electronics for the Fluoride system are designed to be as flexible as possible. A number of programming functions are provided in the CONFIGURATION menu and are protected by an access number, which must be entered to allow changes in these settings. Some settings are for factory use only, while others are used for customer selection of certain operating parameters.
  • Page 20 Model A15/82 Fluoride Monitor with Auto-Calibration SET A F.: LO (OR HI) This routine allows the function of setpoint A to be defined as either low or high. When LO is selected, relay A acts like a low alarm, with the relay activating when the measured fluoride is below the setpoint.
  • Page 21 Model A15/82 Fluoride Monitor with Auto-Calibration CALIBR. T: 3.0’ This routine specifies the amount of time that fluoride standard will be fed into the chemistry module during the automatic calibration routine. The default is 3 minutes, which is the recommended interval. Do not set this value for less than 2 minutes. A longer interval can be used if desired, but is not normally necessary.

  • Page 22: Chemistry Module Startup

    Model A15/82 Fluoride Monitor with Auto-Calibration CHEMISTRY MODULE STARTUP After mechanical and electrical installation is complete, the system is ready for operation. The chemistry module should be placed in operation first. The electronics do not need to be powered during chemistry module startup, but can be powered if desired.

  • Page 23: Automatic Calibration Valve

    Model A15/82 Fluoride Monitor with Auto-Calibration AUTOMATIC CALIBRATION VALVE A 2-way pinch valve is mounted on the bottom of the chemistry module between the sample and reagent pumps. This valve is not required for operation, but is used to automatically switch calibration standard into the measuring cell when called for by the monitor.

  • Page 24: Operation

    Model A15/82 Fluoride Monitor with Auto-Calibration OPERATION With the chemistry module in operation and power turned on to the monitor, the system should now be displaying a fluoride concentration from the sample. The value measured initially will probably be fairly close to the actual value, but the monitor is not factory calibrated.

  • Page 25: Figure 10 - Calibration Hook-Up Diagram

    Model A15/82 Fluoride Monitor with Auto-Calibration for the glass electrode and -405 mV for the polymer sensor). Press ENTER and the display will indicate “P2 DECADE: 100.0”. Press the DOWN key once to change it to “P2 DECADE: 10.00” and press ENTER.

  • Page 26: Automatic Calibration

    MIXING FLUORIDE BUFFER SOLUTION The buffer solution used in the A15/82 Fluoride Monitor is designed to adjust the sample pH to about 5.3 and to provide a relatively stable ionic strength in the sample to allow stable fluoride measurement. The buffer solution can be purchased from ATI or can be mixed by the user if desired.

  • Page 27: Fluoride Calibration Standard

    Model A15/82 Fluoride Monitor with Auto-Calibration FLUORIDE CALIBRATION STANDARD The automatic calibration routine uses a fluoride standard that must be prepared in a 1 gallon container and connected as shown in Figure 5. A 1 gallon container of fluoride standard will last in excess of 6 months assuming if calibration is done every 24 hours and in excess of 1 year if calibration is done every 48 hours.

  • Page 28: Control & Alarm Outputs

    Model A15/82 Fluoride Monitor with Auto-Calibration CONTROL & ALARM OUTPUTS The Fluoride Monitor is equipped with four relay outputs. Two of these outputs are designated control relays, a third is used for alarm functions, and the fourth is used to activate a cleaning cycle. The cleaning cycle function is not implemented in this design as it is not needed for drinking water measurements.

  • Page 29: Alarm Relay

    Model A15/82 Fluoride Monitor with Auto-Calibration ALARM RELAY The A15/82 contains a relay designated as an alarm relay. This relay may be used to warn of various conditions that might indicate operational problems. The relay will activate on either high or low fluoride conditions, and can be used to indicate failure of the control relays to maintain proper control.

  • Page 30: Maintenance

    Model A15/82 Fluoride Monitor with Auto-Calibration MAINTENANCE The A15/82 Fluoride Monitor will generally provide unattended operation over long periods of time. With proper care, the system should continue to provide measurements indefinitely. For reliable operation, maintenance on the system must be done on a regular schedule. Keep in mind that preventive maintenance on a regular schedule is much less troublesome than emergency maintenance that always seems to come at the wrong time.

  • Page 31: Figure 11 - Pump Tubing Assy

    Model A15/82 Fluoride Monitor with Auto-Calibration 3. Replacement tubes are precut to the proper length. For acid feed tubes, place the tubing into the retaining blocks and reinstall the bottom block. Pull the tube around the roller and install the top block.

  • Page 32: Spare Parts - Model A15/82

    Model A15/82 Fluoride Monitor with Auto-Calibration SPARE PARTS - MODEL A15/82 PART NO. DESCRIPTION 00-1214 Complete Fluoride monitor electronics, panel mount 03-0181 NEMA 4X case assembly, (ABS) 63-0045 Sensor cable, 10 ft. 63-0057 Fluoride Sensor 45-0131 Sensor Flow Block 42-0042...
