- Page 1 ® ® Polycom RealPresence Immersive Studio™ System User Guide Version 4.1.3 February 2014 3725-04289-001/A...
- Page 2 Every effort has been made to ensure that the information in this manual is accurate. Polycom, Inc., is not responsible for printing or clerical errors. Information in this document is subject to change without notice.
-
Page 3: Table Of Contents
Use Microsoft Outlook Calendaring ... . 18 Polycom Support and Services ..5 Join Scheduled Meetings ..18 Get Started ... . . 6 Show Content . -
Page 4: About This Guide
® Welcome to immersive collaboration with the Polycom RealPresence Immersive Studio system. The RealPresence Immersive Studio system includes the following features: ● High-quality, 1080p60 video with consistent picture characteristics through all viewing angles ● Polycom 3D Voice audio that delivers immersive sound, eliminating perceptible differences between the sound from remote and in-room participants ●... -
Page 5: Polycom Support And Services
Polycom RealPresence Immersive Studio User Guide About This Guide The Polycom RealPresence Immersive Studio Users’ Guide explains how to use your touch device to operate your RealPresence Immersive Studio 9-seat or 21-seat immersive telepresence (ITP) room system. This guide also describes what you can expect to see on the displays during meetings in the ITP room, and provides general guidelines for conducting successful meetings. -
Page 6: Get Started
Get Started Get Started If you have chosen the optional room sensor, the RealPresence Immersive Studio experience begins when you enter the room. The sensor at the door activates the system, a chime alerts you that the system is enabled, and the monitors display the panoramic wallpaper. -
Page 7: View The Home Screen
Polycom RealPresence Immersive Studio User Guide Get Started View the Home Screen The following table describes information that the Home screen provides. Home Screen Icon and Description Pairing information. Indicates whether a device is paired with the system, the system name, and IP address. - Page 8 To display more information about a meeting or to join a meeting, tap the meeting notice. For more information about connecting to the Microsoft Exchange Server and using Outlook calendaring, refer to the Polycom RealPresence Immersive Studio Administrator’s Guide support.polycom.com.
- Page 9 Polycom RealPresence Immersive Studio User Guide Get Started Home Screen Icon and Description Tap to display options for placing a call. Tap to display options for showing content. Tap to display the view of the local room. View the Home Screen...
- Page 10 Polycom RealPresence Immersive Studio User Guide Get Started Home Screen Icon and Description Tap to mute the microphone in the local room. Tap to display a slider to adjust the volume in the local room. View the Home Screen...
-
Page 11: Place And Answer Calls
Polycom RealPresence Immersive Studio User Guide Place and Answer Calls Place and Answer Calls This section covers video calls, which includes calling into scheduled meetings. When you tap , the preferred form of dialing a call displays. You will see a dialpad or Contacts. - Page 12 Polycom RealPresence Immersive Studio User Guide Place and Answer Calls To place a call to a Favorite contact: 1 Tap 2 From the Favorites list, tap one or more contacts. Tap if the Favorites list does not display. If no favorites are listed, check with your system administrator to determine whether favorites are configured in your system.
- Page 13 Polycom RealPresence Immersive Studio User Guide Place and Answer Calls To place a call to a directory contact: 1 Tap 2 Tap the blank dialing area or tap to display the virtual keyboard. 3 Type the directory entry name that you want to call.
- Page 14 Polycom RealPresence Immersive Studio User Guide Place and Answer Calls 3 Enter the number or name of the contact you want to call. Depending on the capabilities of your system and the system you are calling, the dialing information could look like one of the following examples.
-
Page 15: Dial Passwords Or Extensions
Polycom RealPresence Immersive Studio User Guide Place and Answer Calls Dial Passwords or Extensions To display the dialpad and enter DTMF tones (dial tones) for VMR (bridge) passwords and extensions: 1 Tap on the main screen. 2 Input VMR number 7020000. -
Page 16: In-Call Toolbar
Polycom RealPresence Immersive Studio User Guide Place and Answer Calls In-Call Toolbar When the call connects, the touch device displays the In-Call toolbar, which includes the additional options shown in the following table: Displays a list of participants in the call. -
Page 17: Answer A Call
Polycom RealPresence Immersive Studio User Guide Place and Answer Calls Answer a Call The RealPresence Immersive Studio system displays the name of the caller or system. To answer a call manually: » Tap End a Call To hang up a call: »... -
Page 18: Calendaring
If the meeting organizer has set reminders, the notices are displayed on your touch device. Join Scheduled Meetings If no meetings appear on the RealPresence Immersive Studio Home screen, your system is not connected to the Microsoft Exchange Server. To join a scheduled meeting: 1 Tap the meeting notice. -
Page 19: Show Content
The cables extend out of the pocket as you gently pull them. Recoil the cables gently using the recoil button. For the RealPresence Immersive Studio 21-Seat system, connections are located in the front table only. For best video quality, use refresh rates of 60 Hz or less. Set the resolution and refresh rates according to your computer’s instructions. - Page 20 Polycom RealPresence Immersive Studio User Guide Show Content Supported Resolutions and Refresh Rates Resolution Refresh rates (Hz) 800 x 600 56, 60, 72, 75, 85 1024 x 768 60, 70, 75, 85 1280 x 720 50, 60 1280 x 768...
- Page 21 Polycom RealPresence Immersive Studio User Guide Show Content To show content: 1 Choose one of the following: Out of a call, tap In a call, tap 2 Drag the laptop icon to a monitor icon or the content screen icon To stop content: »...
-
Page 22: Work With Content
Polycom RealPresence Immersive Studio User Guide Show Content Work with Content The RealPresence Immersive Studio system provides quick-swap buttons that enable you to move the content display among monitors. Quick Swap Buttons for Showing Content Label Description Show content on only the top monitor. (default) Show content on only the three bottom monitors. -
Page 23: Hold Effective Meetings
Polycom RealPresence Immersive Studio User Guide Hold Effective Meetings Hold Effective Meetings Conducting a successful meeting in a RealPresence Immersive Studio room is easy. Because you don’t have to manage cameras, microphones, speakers, remote controls, and other equipment, you can concentrate on sharing important information. -
Page 24: System Maintenance
Polycom RealPresence Immersive Studio User Guide Hold Effective Meetings System Maintenance Clean your system regularly to ensure proper functionality. Use the table Recommended Cleaning Procedures for detailed cleaning information. Recommended Cleaning Procedures Component Recommended Cleaning Procedure Front wall panels To remove general soiling and water stains on the laminate surface of and table top the front and back table tops, use a damp cloth. - Page 25 Polycom RealPresence Immersive Studio User Guide Hold Effective Meetings Component Recommended Cleaning Procedure Camera cluster Using a soft sponge, a wool cloth, or chamois, wipe the polycarbonate enclosure and shield with lukewarm water containing a neutral detergent, such as ®...
- Page 26 Polycom RealPresence Immersive Studio User Guide Hold Effective Meetings Component Recommended Cleaning Procedure Chairs For Steelcase-Amia chairs, vacuum or dust the leather frequently with a clean, dry cloth. If the leather is soiled, wipe it with a damp, soft cloth and a lather of any mild soap and a minimum amount of lukewarm water.
- Page 27 Polycom RealPresence Immersive Studio User Guide Hold Effective Meetings Component Recommended Cleaning Procedure Chairs Do not use saddle soap, cleaning solvents, oils, furniture polishes, varnishes, abrasive cleaners, detergents, or ammonia on leather; they will ruin the finish, causing it to become sticky and cracked.
- Page 28 Polycom RealPresence Immersive Studio User Guide Hold Effective Meetings Component Recommended Cleaning Procedure Light fixtures Turn off the power and then wipe the fixtures with a soft, lint-free cloth. Clean the lenses with a dry cloth only. Tablet Keep the touch device free of dirt and dust. For best cleaning results, refer to the cleaning instructions that came with the tablet.
-
Page 29: Regulatory Information
Polycom RealPresence Immersive Studio User Guide Regulatory Information Regulatory Information Regulatory notices describe safety and legal considerations for using the RealPresence Immersive Studio system. Important Safeguards SAVE THESE INSTRUCTIONS Read and understand the following instructions before using the system: ● Always disconnect the system from power before cleaning. -
Page 30: System Rating
Polycom RealPresence Immersive Studio User Guide Regulatory Information System Rating 120/220-240 V~,15/8 A, 50/60 Hz This equipment utilizes multiple disconnects. See the instructions below for quick disconnect of the racks and lighting controller. Please disconnect all before servicing. The main system consists of three independent electronics rack units which are considered “pluggable equipment.”... - Page 31 Polycom RealPresence Immersive Studio User Guide Regulatory Information To disconnect the room lighting from the AC mains supply, turn off the switch labeled (lighting disconnect). Instructions for installer: A readily accessible disconnect device shall be incorporated external to the equipment. Electrician needs to install a single throw double pole switch within a one meter area of the Lighting Controller.
- Page 32 Polycom RealPresence Immersive Studio User Guide Regulatory Information ● A service person must verify that all socket outlets from which the equipment is to be powered provides a connection to the building protective earth. To verify, use a suitable long test/wander lead with an ohm meter/multimeter.
