HIP CHAIR
410
1
PLEASE READ INSTRUCTIONS COMPLETELY BEFORE BEGINNING.
Carefully remove contents from box. Make sure that all parts and hardware are in-
cluded using the Parts List below.
Tools Required:
BACK
ARMREST
50mm HEX LAG
Part Code: 316-1/4-10-50HL
1-5/8" PHILLIPS HEAD SCREW
Actual Size
WARRANTY QUESTIONS OR COMMENTS PLEASE CALL TOLL FREE AT 1-800-809-3114
Seaside Casual Furniture | 11 Industrial Drive Coventry, RI 02816 | 800-809-3114 | sales@seasidecasual.com
ASSEMBLY INSTRUCTIONS
4mm Allen Wrench (included); #2 Phillips Head Screwdriver;
(Recommended: Rubber Mallet; Power Drill)
x 1
x 1
Actual Size
Part Code:
SEAT
x 1
BUMPER
x 4
3/4" PHILLIPS PAN HEAD SCREW
x 6
FRAME
x 4
4mm ALLEN WRENCH
Actual Size
Part Code: 4MMALLEN
Actual Size
Part Code:
x 1
x 1
x 6
