REEL LIFTER FORK ATTACHMENT
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product to determine whether it
sustained damage during transport. If damage is found, record a complete description of it on the bill of
lading. If the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, installation, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
