Description And Application - Ada Vertical Operating Manual

ADA VERTICAL presents the instrument of vertical projection with laser emitter, class 2. Do not look into the laser beam
and do not aim at other persons.

1. Description and application

1) Transmission of planned position with the help of optical method or laser beam;
2) Bright visible red laser beam (635nm);
3) Brightness adjustment of laser beam;
4) Adjustment of diameter of laser spot to increase measurement accuracy;
5) Laser target with reticular division;
6) Bubble levels with LED backlight;
Laser beam is combined with axis of sight of telescope. Such alignment is very convenient when measuring. Because
it's possible to make optical and laser measurements simultaneously. With the help of telescope it's possible to control
the position of laser spot and transmit planned position of the dot in vertical direction.
Instrument of vertical projection is widely used by professionals for control when building elevator well, setting supports
for high-tension lines, building bridges and tunnels, skyscrapers, water towers, chimneys and for other works where it's
necessary to have constant control.
Complete set
- instrument of vertical projection 1
- operating manual
- target plate
- ilter
- calibrating pin
- case
- batteries
1
1
1
1
1
2

VERTICAL
MEASUREMENT FOUNDATION
