3.INSTALLATION

3.3 Assembling
1. Choose a flat and level 2. Extend the liner to the chosen
location. area.
4. Adjust the 8 segments until 5. Install the connection hose on
C
they form a perfect round shape. the liner.
Then, ensure that the holes for
M the outer liner connection and
the holes in the foam wall are
still aligned.
Y
CM
MY
CY
CMY
K
7. Install the connecting hose 8. Install two-way connector to
another outlet, as shown in the
(assemble the short hose and
T-join as shown in the image). image.
10. Insert the hose into the 11. Connect the other end of the hose of the two-way connector, as
groove on the foam, as shown shown in the image.
in image.
12. After all hoses are installed, lift the outer cover gently, as shown
in the image.
11
3. Add the foam wall segment
with the three holes in it for
connection to the base liner.
6. Insert the inner liner of your spa.
9. Connect the longest
connecting hose to the T-joint
as shown in the image.
13. When installed at corner,
push PE foam inward so that
the coat can be installed in
place.
3.INSTALLATION
14. Locate the place where 15. Smooth the liner all around
the two zippers are aligned, the SPA to ensure a good fit.
connect them first
18. Make sure that the zippers
17. Locate the place where
of the liner and outer liners are
the two zippers are aligned,
connect them first. aligned before zipping them up.
20. Insert the cartridge into its 21. Check that the drain plug is
filter holder and then screw on closed properly.
the suction fitting inside the
basin.
3.4. Pool cover and security
After each use, the control panel must be locked and the pool must
be coated with its top cover and it must be attached to the base
protector with the safety buckles.
Each safety buckles has a lock system ; closed buckle, the latch in
up position locks the buckle, the latch in down position unlocks the
buckle.
The top cover keeps the heat from the water and secures the pool.
EN
16. When installed at corner, push
PE foam inward so that the coat can
be installed in place.
19. Connect the unit pump to the
pool using the 3 connectiors to
screw. Ensure the icons on the
pump and the pool match up.
22. Fill the spa pool until the indicat -
ed fill level is reached.
Your spa is ready to be used.
