Original SLANTBACK
INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
Thank you for purchasing an ACCESS
pride using superior quality materials and craftsmanship. With proper care, your cover will provide
years of service and enjoyment.
NOTICE TO INSTALLER: It is recommended you take the time to read these instructions
before installing this cover even if already familiar with the product. Often improvements
are made without prior notice. Always handle cover and components with care to avoid damage.
If you find a part missing or defective, or if you are having trouble installing this product, please
have serial number ready (found on decal under rear bar by tailgate) and call the customer service
number on the back page. When done, these instructions and warranty information must be
given to the consumer.
NOTICE TO CONSUMER: Before using this product, read the operating instructions,
maintenance and safety sections of this owners manual and save for future reference.
HELP LINE
HELP LINE
Roll-Up Cover
®
Roll-Up Cover. ACI has manufactured this roll-up cover with
®
Tested. Trusted. Guaranteed.
validate the warranty. Go online to
www.agricover.com/productregistration
Call Customer Service:
(701) 251-1427
www.accesscover.com/faq
Product must be registered to
or complete the registration
form on Page 11.
