INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
Thank you for purchasing an ACCESS Vanish roll-up cover. ACI has manufactured this roll-up cover
with pride using superior quality materials and craftsmanship. With proper care, your cover will
provide years of service and enjoyment.
NOTICE TO INSTALLER: It is recommended you take the time to read these instructions before
installing this cover even if already familiar with the product. Often improvements are made
without prior notice. Always handle cover and components with care to avoid damage. If you find
a part missing or defective, or if you are having trouble installing this product, please have serial
number ready (found on decal under rear bar by tailgate) and call the customer service number on
the back page. When done, these instructions and warranty information must be given to the
consumer.
NOTICE TO CONSUMER: Before using this product, read the operating instructions, mainte-
nance and safety sections of this owners manual and save for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Access Vanish
Summary of Contents for Access Vanish
- Page 1 INSTALLATION INSTRUCTIONS AND OWNER’S MANUAL Thank you for purchasing an ACCESS Vanish roll-up cover. ACI has manufactured this roll-up cover with pride using superior quality materials and craftsmanship. With proper care, your cover will provide years of service and enjoyment.
- Page 2 INSTALLATION INSTRUCTIONS: (NOTE: For additional installation assistance visit us at www.vanishcover.com) PREPARATION Unpack cover components. Clean truck box if dirty. COMPONENTS: 1 driver side rail 1 passenger side rail 6 clamps 1 left and 1 right tension adjuster with nuts & bolts 1 pre-rolled up cover TOOLS NEEDED: 1 - 1/2”...
- Page 3 1. INSTALLING COVER SIDE RAILS CONT’D. C. Next install a 2nd clamp at midway Second clamp point of box and rail. Now check rail for level. See photo at left and illustration below. If rail tilts up, move clamps down and tighten.
- Page 4 3. MOUNTING COVER TO SIDE RAILS A. Set rolled up cover on rails at front of box (behind cab) with bar facing up. Roll cover bar onto front of rails and fold/tuck vinyl flap under. Now bar will face down. Let straps hang to inside of box.
- Page 5 4. INITIAL OPERATION AND ADJUSTMENTS A. Unroll cover and place rear bar into strikes on side rails and press down on bar to close (20-30 pounds pressure). B. Close tailgate slowly - top of tailgate should fit snug under cover bar. If tailgate rubs bar too hard, raise rails by loosening rear clamps, adjust rails up and retighten clamps.
- Page 6 OPERATING INSTRUCTIONS Note: view opening and closing demonstration video on www.vanishcover.com Release retainer straps at front Position roll-up bar against Now along side of box, seal cover and using both hands roll cover strikes. Push down on bar until edges with hook and loop sealing out to rear of box.
- Page 7 SAFETY INFORMATION • Do not cover cargo that is higher than the cover. • Do not place object(s) on or against the cover or its framework at any time. • Always secure cargo so it cannot shift and damage the cover or its parts. •...
- Page 8 TROUBLESHOOTING PROBLEM SOLUTION Cover too loose Turn both tension adjusters counter clockwise to move front bar forward (Refer to #4C, see arrows next to adjuster) Cover too tight Turn both tension adjusters clockwise to move front bar forward (Refer to #4C, see arrows next to adjuster) Gap between roll-up bar and tailgate Rails set too high (Refer to #4B) Cover is too wide Check rails.
