Furniture of America CM3318PC-2PK Assembly Instructions

Download this manual

Assembly Instructions

CM3318PC-2PK

ASSEMBLY RATING

Tools Required for Assembly:

The Assembly Rating is a 5-point system that

shows the degree of effort needed in

Allen Wrench

assembling a specific product (with 1 being

(Included)

easy and 5 being difficult). For some

products, two persons are recommended.

Phillips Screwdriver

(Not Included)

DIFFICULT

EASY

Page 1 of 5

Rev.14-03-05

Need help?

Do you have a question about the CM3318PC-2PK and is the answer not in the manual?

Page 1 Assembly Instructions CM3318PC-2PK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult). For some products, two persons are recommended.
Page 2 Page 2 of 5...
Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 10 pcs Backrest w/Legs Flat Washer 1/4” #B x 10 pcs #2 x 1 pc Lock Washer 1/4”...
Page 4 Place the backrest with legs (#1) on a protected surface. Align the seat frame with cushion (#2) with the pre-drilled holes of Step 1 the backrest with legs (#1). III. Prepare 2 bolt assemblies by inserting FIRST the lock washer (#B) onto the bolt (#C) and then the flat washer (#A) onto the SAME bolt (#C), in that order.
Page 5 Note: Right and left is determined by standing in FRONT of the chair in its upright position. Step 3 #A x 4 pcs #B x 4 pcs #D x 4 pcs Align the left front leg (#3) with the two pre-drilled holes of the seat Enlarged frame with cushion (#2).
