ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3156PC-2PK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
Page 1 of 6
(Included)
(Not Included)
Rev: 18-06-23
Advertisement
Table of Contents
Related Manuals for Furniture of America CM3156PC-2PK
Summary of Contents for Furniture of America CM3156PC-2PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3156PC-2PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc x 2 #A x 4pcs x 2 Chair Back Bolt Ø1/4"x3-1/8" #B x 4pcs x 2 #2 x 1pc x 2 Cushion Seat Bolt Ø1/4"X2-1/2"...
- Page 4 Exploded View Insert dowel (#G) to the middle hole of the chair back (#1), then align seat (#2) to the holes of the chair back (#1). Secure middle two holes of the seat (#2) to chair back (#1) by using bolts (#C) with washers (#D,E). #C x 2pcs #D x 2pcs #E x 2pcs...
- Page 5 Secure corner holes of the seat (#2) to chair back (#1) by using bolts (#A) with washers (#D,E). #A x 4pcs #D x 4pcs #E x 4pcs Align front legs (#3,4) to the holes of the seat (#2), then secure by using bolts (#B) with washers (#D,E).
- Page 6 Secure stretchers (#5,6,7) by using screws (#F). #F x 6pcs ASSEMBLY IS COMPLETED Page 6 of 6...
