METAL ROOF 10'x10' GAZEBO
ASSEMBLY INSTRUCTIONS
DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED
FOR FUTURE REFERENCE,
TAKE PICTURES OF ALL SIX SIDES OF EACH OF THE BOXES UPON RECEIPT.
PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS
Assembly with more than one person recommended
Base Dimensions 8'9" x 8'9"
APPROX.
Largest Dimensions 9'9" x 9'9"
Overall Height 108.5''
ZZZ-212.43200MR.0608-20.GP.EN.doc
WEB VERSION
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 43200MR-22 and is the answer not in the manual?

Questions and answers

Related Manuals for Gazebo penguin 43200MR-22

Summary of Contents for Gazebo penguin 43200MR-22

  • Page 1 43200MR-22 BROWN 43200MR-32 SLATE METAL ROOF 10’x10’ GAZEBO ASSEMBLY INSTRUCTIONS DO NOT DESTROY THE BOXES UNTIL COMPLETELY ASSEMBLED FOR FUTURE REFERENCE, TAKE PICTURES OF ALL SIX SIDES OF EACH OF THE BOXES UPON RECEIPT. PLEASE VERIFY THE CONTENT OF EACH BOX AGAINST THE LIST OF PARTS Assembly with more than one person recommended Base Dimensions 8’9”...
  • Page 2 Some jurisdictions may require permits for, or otherwise regulate, installation and use. For assistance with assembly, installation, parts, or customer service, contact Gazebo Penguin Customer Service Department at the numbers listed below (English & French, Mon-Fri 8:00 AM to 4:00 PM EST):...
  • Page 3 3. Leaking due to heavy rain may happen, please refer to the instruction manual for window positions and information on how to evacuate the water. 4. The product is only warranted in the event it is installed in accordance with the Gazebo Penguin’s written instructions enclosed with the product.
  • Page 4 43200MR BROWN (see page 7 for Slate parts) PART DIAGRAM PART DIAGRAM (11-624-22) (20-013-22) 52 ¾” 83” TOP LEFT ROOF RAFTER BEAM (11-625-22) (20-014-22) 52 ¾” 60 3/8” TOP RIGHT ROOF RAFTER BEAM (11-628-22) (20-015-22) CORNER FINISHING BAR PLATE (11-629-22) (20-065-22) CENTER FINISHING BAR...
  • Page 5 PART DIAGRAM PART DIAGRAM 18-067-22 (20-010-22) SOLIDIFYING LEFT UPPER ROOF PANEL BRACKET 20-060-22 (08-158-22) SOLIDIFYING BOLT (M6x16mm) BRACKET (20-070-22) 55 ¼” (08-156-22) RIGHT SCREW (M4x16mm) FLASHING (17-053-22) (08-167-22) FINISHING SCREW (M6x63.5mm) (19-097-22) (08-193-22) CORNER PLASTIC PLUG BRACKET (20-071-22) (08-187-22) 55 ¼” LEFT WASHER FLASHING...
  • Page 6 PART DIAGRAM PART DIAGRAM *NOT INCLUDED IN THE BOX (16-118-22) SCREW M6*36 COLOUR PART # DESCRIPTION (11-705-22) SPRAY PAINT 11-726 CURTAIN BROWN PAINT PEN 18-184 HOOKS (08-182) 10 mm KEY ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 7 43200MR SLATE PART DIAGRAM PART DIAGRAM (11-624-32) (20-013-32) 52 ¾” 83” TOP LEFT ROOF RAFTER BEAM (11-625-32) (20-014-32) 52 ¾” 60 3/8” TOP RIGHT ROOF RAFTER BEAM (11-628-32) (20-015-32) CORNER FINISHING BAR PLATE (11-629-32) (20-065-32) CENTER FINISHING BAR PLATE (11-630-32) (20-017-32) 81 ½”...
  • Page 8 PART DIAGRAM PART DIAGRAM 18-067-32 (20-010-32) SOLIDIFYING LEFT UPPER ROOF PANEL BRACKET 20-060-32 (08-158-32) SOLIDIFYING BOLT (M6x16mm) BRACKET (20-070-32) 55 ¼” (08-156-32) RIGHT SCREW (M4x16mm) FLASHING (17-053-32) (08-167-32) FINISHING SCREW (M6x63.5mm) (19-097-32) (08-193-32) CORNER PLASTIC PLUG BRACKET (20-071-32) (08-187-32) 55 ¼” LEFT WASHER FLASHING...
  • Page 9 PART DIAGRAM PART DIAGRAM *NOT INCLUDED IN THE BOX (16-118-32) SCREW M6*36 COLOUR PART # DESCRIPTION (11-705-32) SPRAY PAINT 18-125 CURTAIN SLATE PAINT PEN 18-126 HOOKS (08-182) 10 mm KEY ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 10 Before You Assemble the Gazebo  Please don't destroy boxes until completely assembled.  For future reference, take pictures of all six sides of each of the boxes upon receipt.  Please verify the content of each box against the list of parts. ...
  • Page 11 ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 12 Step 2: 1. For each Leg “G”, attach Foot Plate “H” using 3 Bolts “Pp”. Step 3: 1. Unscrew 4 “Pp” Bolts as shown below, have someone lift the Beam assembly and attach each Leg “G” into a Corner, again securing each using 4 Bolts “Pp”. 2.
  • Page 13 Step 4: 1. Install Middle Cover “J” at each of the 4 beam junctions, using 4 Screws “Qq” each. 2. Install Corner Cover “I” at each of the corners, using 4 Screws “Qq” each. ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 14 Step 5: 1. Screw Mounting Bracket (O) to Rafter (L1) and Bracket (P) to Rafter (L2) using the second last single insert from under the rafter using Bolt (Pp) 2. Attach Roof Rafters (L1, L2) to the Central Hub (L) using Bolt (Pp). 3.
  • Page 15 Step 6: 1. Install the Flashings “Q” and “R” onto the Beam assembly, using screws “Qq” on the inside. The notched end of a Flashing will always go in a corner of the gazebo. Step 7: 1. Install the Curtain Rails “T” on the inside of the beam assembly using bolts “Pp”. ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 16 Step 8: 1. Place Roof Finishing Bars (M, M2) next to each other and align with the holes in each bar one on top of the other. 2. Place Finishing End & Corner Bracket (Q1, Q2) under the aligned holes and secure with Bolt (Pp).
  • Page 17 Step 9: 1. From the inside of the solarium, install the solidifying bar (N, N1) as illustrated using the bolts (Pp). 2. Each bolt (Pp) must be inserted into the inserts of the roof bars. ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 18 Step 10: 1. Install the Bottom Roof Panels (V, V1) by sliding them onto finishing bar (M & M2). Step 11: 1. Install first roof panel (X1) by sliding it on top of roof rafters (L1, L2). Note: Roof Panel must be held in place until it is secured with the Cover Cap. ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 19 Step 12: 1. Once the installation of the panel is complete, install a cover roof bar (O, O1) onto the roof bar (L1, L2) with the help of bolts (Oo1). 2. Place Cover Roof Bar on top of Rafter, but do not completely screw it until both panels connected to the roof bar are placed.

  • Page 20: Top View

    Step 13: 1. Install the next upper roof panel (X) by sliding it on top of roof rafters (L1, L2) then secure with mutual Cover Roof Bar. 2. Continue to install the other panels one at the time until the last section. TOP VIEW ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 21 Step 14: Before installing last Roof Panel, put Cap (K) on top of the Central Hub (L) ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 22 Step 15: Install the last upper Roof Panel (X1). ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 23 Step 16: 1. Once the last Roof Panel is installed, screw last Cover Roof Bar (O1, O2) to the Rafter (L1,L2) with Bolts (Oo1). O1/O2 L1/L2 ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 24 Step 17: Use Nut (Vv) to affix Top Cap (K) to the Central Hub (L). ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
  • Page 25 Step 18: 1. Secure each foot plate into the ground using Screws “Rr” and Washers “Tt”. 2. Use Lag Shields (Ss) if needed for harder surfaces. Step 19: 1. Install the Screen Curtains “Ww” in the interior groove of the Curtain Rails, using the provided Hooks.
  • Page 26 NOTE: The Dimensions Are Approximate. ZZZ-212.43200MR.0608-20.GP.EN.doc WEB VERSION...
