VOL-079
Matchplay Volleyball Posts
C/W Stainless Steel Winch
*Net sold separately
2 people are recommended for this assembly
30
Estimated 30 minutes assembly time (not including time for concrete)
mins
i
IMPORTANT: Please read these assembly instructions carefully before
starting to anchor your Volleyball Posts
INS079
Revision 0
09/06/2017
Advertisement
Table of Contents
Related Manuals for Harrod VOL-079
Summary of Contents for Harrod VOL-079
- Page 1 ASSEMBLY INSTRUCTIONS INS079 Revision 0 VOL-079 09/06/2017 Matchplay Volleyball Posts C/W Stainless Steel Winch *Net sold separately 2 people are recommended for this assembly Estimated 30 minutes assembly time (not including time for concrete) mins IMPORTANT: Please read these assembly instructions carefully before...
- Page 2 Code VOL-079 Product Matchplay Volleyball C/W Stainless Steel Winch Pack Contents Matchplay Volleyball Posts Winder Post Dummy Post Base Optional Extras VOL-001 3mm No.30 Net VOL-053 Post and Base Protector SHP-001 SH2 Anchor 160mm SHP-100 SH2 Anchor 200mm FEQ970 FEQ976...
- Page 3 Code VOL-079 Product Matchplay Volleyball C/W Stainless Steel Winch Socket Installation Drill four Ø20 holes to the dimensions shown and to the correct depth of the purchased sockets. 20mm PLAN VIEW 11m Socket Centres IMPORTANT: Floor sockets are not included and should be ordered separately.
- Page 4 Code VOL-079 Product Matchplay Volleyball C/W Stainless Steel Winch Assembly Instructions Attach the Brace (packed with Winder and Dummy Posts) to the Post and Base 17mm HINT: Position holes in the Brace on the inside. To attach the Net, feed the loops through the top of the Pulley Wheel and through the Eye Hooks.
