I
NSTRUCTION MANUAL
SOMNOwatch
VERSION 07.11.2012
Caution: Federal law restricts this device to sale by or on the order of a physician.
SOMNOmedics GmbH – Am Sonnenstuhl 63 – D-97236 Randersacker
Phone.: +49 (0) 931 / 35 90 94-0 – Fax: +49 (0) 931 / 35 90 94-49
E-Mail: info@somnomedics.de – Internet: www.somnomedics.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOMNOwatch and is the answer not in the manual?

Questions and answers

Related Manuals for SOMNOmedics SOMNOwatch

Summary of Contents for SOMNOmedics SOMNOwatch

  • Page 1 Caution: Federal law restricts this device to sale by or on the order of a physician. SOMNOmedics GmbH – Am Sonnenstuhl 63 – D-97236 Randersacker Phone.: +49 (0) 931 / 35 90 94-0 – Fax: +49 (0) 931 / 35 90 94-49...
  • Page 2 SOMNOmedics GmbH – Am Sonnenstuhl 63 – D-97236 Randersacker Phone: +49 (0) 931 / 35 90 94-0 – Fax: +49 (0) 931 / 35 90 94-49 E-Mail: info@somnomedics.de - Internet: www.somnomedics.eu Rev. 3 07.11.2012 All proper names marked with TM are protected copyright by SOMNOmedics.

  • Page 3: Table Of Contents

    Configurations ..........................7 Safety instructions ......................... 9 Docking Station Driver Installation .................... 10 WinXP ............................10 Operating Instructions ......................... 11 How to switch the SOMNOwatch On ..................11 Recording Measurements ......................11 5.2.1 Safety Instructions ......................11 5.2.2 Initializing the SOMNOwatch ................... 11 5.2.3...
  • Page 4 Medic al Devic es for Sleep Diagnostic s and T hera py Contact ............................. 25 10 Notes ............................. 26...

  • Page 5: Introduction

    Medic al Devic es for Sleep Diagnostic s and T hera py 1 Introduction SOMNOmedics thanks you for purchasing this product. We are confident that you enjoy using the SOMNOwatch for many years. The SOMNOwatch has been developed by SOMNOmedics to meet the highest quality control standards available.

  • Page 6: About The Somnowatch

    Please refer to the safety instructions in chapter 3. 2.2 Model and Device Number When unpacking the SOMNOwatch, check to make sure that all items are in good condition and that all accessories correspond to the delivery note. Also compare the Model on the delivery note with the label on the bottom of SOMNOwatch (see fig.

  • Page 7: Elements Of Keyboard

    This sensor measuring the intensity of the ambient light. 2.4 Configurations The SOMNOwatch is available in 5 different configurations. All configurations include a SOMNOwatch with Docking Station and Battery Charger, a USB adapter cable, a Carry Bag for housing the SOMNOwatch and Sensors, Instruction Manuals and the DOMINO light software for Initialisation, Data Transfer and Analysis.
  • Page 8 Medic al Devic es for Sleep Diagnostic s and T hera py Actigraphy/ Actigraphy/ Actigraphy / Actigraphy/ Actigraphy/ Actigraphy PLM- Respiratory Long-Term Long-Term Temperature MODULES, Analysis Screening CHANNELS, ACCESSORIES Integrated Channels 3 Activity Sensors ● ● ● ● ● ● (X,Y,Z –...

  • Page 9: Safety Instructions

    This device complies with the IP-Protection-Class "54". This Classification states that the SOMNOwatch is dust and splash proof. Do not use an autoclave for cleaning the SOMNOwatch or any of its accessories, cables and sensors. Follow the manufactures instructions when using disinfectants. Keep to the prescribed dose and contact time.

  • Page 10: Docking Station Driver Installation

    Medic al Devic es for Sleep Diagnostic s and T hera py 4 Docking Station Driver Installation 4.1 WinXP The first time you connect the SOMNOwatch Docking Station to a USB-port the following window will occur: Click on Continue Anyway to start the installation of the driver.

  • Page 11: Operating Instructions

    5.2 Recording Measurements 5.2.1 Safety Instructions The date and time of the PC system clock is delivered to the SOMNOwatch during the initialisation. Therefore it is important to have preset the right date and time. Please note that measuremets running during the change of Summer/Winter time will have a time shift.
  • Page 12 Medic al Devic es for Sleep Diagnostic s and T hera py Patient Data Input: Enter the data into the corresponding fields (see fig. 5-2). Type carefully as this information will be saved for later use. It is important to enter a Patient ID number. This number is used to store the Patient Data in the optional Patient Database.
  • Page 13 Medic al Devic es for Sleep Diagnostic s and T hera py Now you have to choose a montage. The channels which will be recorded are defined here. Descriptions (see fig. 5-4 and fig. 5-5 ) Montages: (1) Select an already existing montage or define a new one with the button Save as Power-Saving Mode:(2) The activity sensor for the Z-Axis, the body position sensor...

  • Page 14: Readout Of Measurement

    Medic al Devic es for Sleep Diagnostic s and T hera py 5.2.3 Readout of measurement Once there are one or more measurements on the SOMNOwatch, it is possible to readout these with the DOMINO light Software and the Docking Station.

  • Page 15: Attachment Of External Sensors

    Medic al Devic es for Sleep Diagnostic s and T hera py 6 Attachment of external Sensors External sensors have to be plugged just into the auxiliary input (AUX). Important for the operator is, that he selects a corresponding montage for the used sensor to avoid confusion. 6.1 PLM Sensor In order to measure leg movements simultaneous on both legs to detect periodic limb movement (PLM) or the restless legs syndrome (RLS) an external PLM sensor can be used to measure the...

  • Page 16: Respiratory Pressure Sensor For Flow And Snore (Blue)

    6.2 Respiratory Pressure Sensor for Flow and Snore (blue) To use the SOMNOwatch as a respiratory screener an external pressure sensor has to be connected to the AUX input. The nasal or naso/oral canula, which leads the air to the sensor, is applied to the patient by putting the tube behind the ears and fixing the canula by pushing the sleeve (fig.

  • Page 17: Ecg Sensor

    ECG Sensor If the SOMNOwatch should record an ECG the sensor has to be plugged in the AUX input. The ECG sensor has three fittings for snap electrodes. One is on the back of the blue disc and the others are green and yellow.

  • Page 18: Eeg Sensor

    EEG Sensor To record an EEG with the SOMNOwatch the EEG sensor has to be plugged into the AUX input. The EEG sensor has three fittings for snap electrodes. One is on the back of the blue disc and the others are red and marine blue.

  • Page 19: Troubleshooting

    Possible Reason What to do? Analysis Unable to start Display Registration code Contact SOMNOmedics Support and request the Programme. not entered. registration code. Enter the registration code into the Global Preferences in the Folders menu. After entering the code, click on the Save and Exit button.

  • Page 20: Maintenance

    Other disinfectants, approved by DGHM, may be used after testing that they do not damage the surface of the device or the sensors. Do not use an autoclave for cleaning the SOMNOwatch or any of its accessories, cables and sensors.
  • Page 21 Medic al Devic es for Sleep Diagnostic s and T hera py Disinfection of Sensors, Electrodes and Belts: Article Disinfectant Concentration Duration Intervals Other (trade mark) Pneumatic Quick After use Remove adhesives if Sensor (Flow/ disinfection using necessary. Follow Snore and Alcohol type manufacturers CPAP)

  • Page 22: Use And Maintenance Of The Rechargeable Battery

    Medic al Devic es for Sleep Diagnostic s and T hera py Use and Maintenance of the Rechargeable Battery The internal battery is a Lithium-Ion (Li ION) rechargeable battery. The battery offers a long life (approximately 500 charges), is not susceptible to memory effects and is ecologically friendly. It takes approximately 1.75 h to charge a fully flat battery.

  • Page 23: Service

    Medic al Devic es for Sleep Diagnostic s and T hera py 9 Service 9.1 Technical specification 7 CHANNELS 6 Internal Channels: 3 Activity Sensors for X-Y-Z Axis, Body Position, Ambient Light, Patient Marker) 1 External Channel: Signal Input AUX DATA PROCESSING 12 Bit ADC Different Sampling Rates Adjustable ( 1/120s - 128/s )

  • Page 24: Malfunctions

    The device is not working correctly (poor measurements) Components are loose or fit poorly Connectors are damaged (crushed or cut cables) Please contact your local distributor for a fast response or contact SOMNOmedics for a fast and efficient response. Please see chapter 9.6. 9.3 Warranty...
  • Page 25 +49 (0) 9 31 / 35 90 94 49 We also provide service and support via e-mail on: service@somnomedics.de Unfortunately it is sometimes possible that our hotline may be busy when you call and you will be redirected to our mailbox. When this happens, please leave your name and telephone number so that...
  • Page 26 Medic al Devic es for Sleep Diagnostic s and T hera py 10 Notes...
