Summary of Contents for Amprobe TMA40-A

  • Page 1 For detailed specifications and ordering info go to www.TestEquipmentDepot.com TMA40-A Airflow Anemometer Users Manual For detailed specifications and ordering info go to www.TestEquipmentDepot.com...
  • Page 2 TMA40-A Airflow Anemometer Users Manual TMA40-A_Rev002 © 2009 Amprobe Test Tools. All rights reserved.
  • Page 3 Limited Warranty and Limitation of Liability Your Amprobe product will be free from defects in material and workmanship for 1 year from the date of purchase. This warranty does not cover fuses, disposable batteries or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
  • Page 4 1 SYM. 2 ABC DEF 3 MNO 6 5 JKL 4 GHI 7 PQRS WXYZ 9 8 TUV ON/OFF MEAS: Normal (Single) measurement MEM : Manual record(99 points) measurement LOG : Automatic record (Logger) measurement : Logger, Unit, real time, other setting ➊...
  • Page 5: Table Of Contents

    TMA40-A Airflow Anemometer CONTENTS introduction ............................5 Unpacking and inspection .........................5 operation ............................5 Meter setting: SeT (See fig.2) .......................5 Meter Screen description (See figs 2&3) ..................5 Single Measurement: MeAS (See fig. 3) ..................6 Multiple Measurement: MeM (See fig. 4) ..................6 Automatic logging: log (See fig. 5) ...................6 Comparison Table ..........................7...
  • Page 6: Introduction

    4-pcs AAA batteries or 9V adaptor (not included) (plug: outer:5.5mm; inner:2.1mm; Center positive) 0.05mA minimum UNPACKING AND INSPECTION Your shipping carton should include: 1 x TMA40-A Airflow Anemometer 4 x AAA battery 1 x USb Cable 1 x Cd download Suite...
  • Page 7: Single Measurement: Meas (See Fig. 3)

    id: press ediT to enter the user id. Use the keypad to enter the information. Note: To calculate air volume, first enter the value of the air source area. Three choices are available: length x width (rectangle); diameter(Circle); and Area. Range from 0~300cm (Rectangle and Circle and 0~90000sq.cm for area.
  • Page 8: Comparison Table

    • press nexT • press p-pg(previous page) or n-pg (next page) to see the previous or the next 100 points. • press bACK • press exiT to return to the main screen COMPARISON TABLE Measurement Description Memory Point Single point Single point measurement no Memory file name editable...
  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS Temperature resolution 0.1°C (0.1°f) Temperature response 30 seconds Relative humidity range 0 to 100% Rh accuracy ± 3% at 10% to 99%; ± 5% at all others Rh resolution 0.1% Rh response time 15 seconds wet bulb range -22 to 70°C (-7.6°f to 158°f) wet bulb resolution Air Velocity range...
  • Page 10: Troubleshooting

    -insert the software Cd into Cd-RoM driver -install the USb driver first -install the software follow the on-screen instructions -open the program -Click the “port” from main screen and input the right comm. port. -Click as follow to download the memory Click to download manually recorded data.
  • Page 11 Welcome Welcome MEAS MEAS LCD Cont.(1-5): 3 LCD Cont.(1-5): 3 Prn Cont. .(1-9): 5 Prn Cont. .(1-9): 5 Auto Off: 20 mins Auto Off: 20 mins Enable Enable EXIT EDIT NEXT EXIT EDIT NEXT Set Clock: Set Clock: MM-DD-YY HH:MM:SS MM-DD-YY HH:MM:SS 02-28-08 18: 29: 20...
  • Page 12 Welcome Welcome MEAS MEAS 001: WBT: WBT: VOL: VOL: NEXT NEXT EDIT START EXIT MEAS EXIT Begin: 02-13-08 Start: 04:25:36 End: 02-25-08 Suspend: 02:44:15 29.7°C 73.7% Rate: 60Sec(s) Expect: 2400Points WBT: VOL: Remain: 2300Points 26.1°C 0.1CMM EXIT EDIT VIEW NEXT ABORT SAVE Press START to begin...
